Specications
n
Product Specications
Model PN-R706 PN-R606
LCD component
70" Class
[69-1/2 inch (176.56 cm) diagonal]
TFT LCD
60" Class
[60-1/8 inch (152.66 cm) diagonal]
TFT LCD
Max. resolution (pixels)
1920 x 1080
Max. colors
Approx. 1.06 billion colors
Pixel pitch
0.802 mm (H) × 0.802 mm (V) 0.693 mm (H) × 0.693 mm (V)
Max. brightness (typical) 700 cd/m
2
*
1
Contrast ratio (typical) 5000: 1
Viewing angle
176° right/left/up/down (contrast ratio ≥ 10)
Screen active area inch (mm)
60-9/16 (W) x 34-1/16 (H)
(1538.88 x 865.62)
52-3/8 (W) x 29-7/16 (H)
(1330.56 x 748.44)
Computer input signal
Digital (DVI 1.0 standard-compliant), Analog RGB (0.7 Vp-p) [75 Ω],
DisplayPort 1.2, HDMI
Sync signal
Horizontal/vertical separate (TTL: positive/negative), Sync-on-green*
2
,
Composite sync (TTL: positive/negative)
*2
Plug and play
VESA DDC2B
Power management
VESA DPMS, DVI DMPM
Input terminals
Video HDMI x 2
DVI-D 24 pin (HDCP compatible) x 1
Mini D-sub 15 pin, 3 rows x 1
DisplayPort x 1
Audio
3.5 mm mini stereo jack x 1
Serial (RS-232C)
D-sub 9 pin x 1
Output terminals
Video DisplayPort x 1
Audio
3.5 mm mini stereo jack x 1
Serial (RS-232C)
D-sub 9 pin x 1
LAN terminal 10 BASE-T/100 BASE-TX
Power supply terminal 5 V, 2 A (5 V, 500 mA when the expansion slot is used)
(USB Type-A connector)
Expansion slot 12 V, 2.4 A
(power supplied when expanding the functions with an optional part)
Speaker output 10 W + 10 W
Power requirement AC 100 - 240 V, 2.6 A, 50/60 Hz AC 100 - 240 V, 2.2 A, 50/60 Hz
Operating temperature
*
3
32°F to 104°F (0°C to 40°C)
Operating humidity 20% to 80% (no condensation)
Power consumption
(Input signal waiting mode
*
4
/ standby mode
*
5
)
230 W
(2.5 W / 0.5 W)
190 W
(2.5 W / 0.5 W)
Dimensions (excluding protrusions) inch (mm)
Approx. 62-3/16 (W) x 2-9/16 (D) x
36-1/8 (H) (1579 x 65 x 918)
Approx. 53-1/8 (W) x 2-3/8 (D) x
30-1/2 (H) (1349 x 60 x 775)
Weight lbs. (kg)
Approx. 99.3 (45) Approx. 72.8 (33)
*1 Brightness will depend on input mode and other picture settings. Brightness level will decrease over time. Due to the nature of the
equipment, it is not possible to precisely maintain a constant level of brightness.
*2 D-Sub input terminal only.
*3 When using the monitor laying at on a surface (when the monitor is tilted more than 20 degrees upward or downward from the
perpendicular in relation to a level surface), use the monitor at a temperature between 32°F (0°C) to 86°F (30°C).
Temperature condition may change when using the monitor together with the optional equipments recommended by SHARP. In such
cases, please check the temperature condition specied by the optional equipments.
*4 When SUPPLY USB POWER is set to POWER ON ONLY and no optional part is attached.
*5 When POWER SAVE MODE is set to ON, SUPPLY USB POWER is set to POWER ON ONLY, and no optional part is attached. When
POWER SAVE MODE is set to OFF: 0.8 W
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specication changes for product improvement
without prior notice. The performance specication gures indicated are nominal values of production units. There may be some deviations from
these values in individual units.
