Sharp PN-CD701 Installation Guidelines

Confidential
Copyright © All rights reserved, SHARP CORPORATION
1
About handling of this material / Contents
・ Please handle this document very carefully as it includes
know-how of information displays.
・ Basic notes of installation to use the display for long term in
good condition is described
Contents
1. Precautions for temperature, clearance and
environment … 2
2. Precautions for opening the package … 3
3. Precautions for installation and handling … 4
4. Conditions of tilt angle … 6
5. Precautions for a stand installation … 7
6. Precautions for transportation of packed display
…11
7. Other precautions …15
8. Option parts list …16
9. System requirement …17
10. USB Cable Connection …18
11. Handling of PN-ZU01 (8m USB-C Cable) …19
12. How to connect using USB-C Out …20
13. Notes on setup …21
14. About HIDDEN MENU …23
About handling of this material
[Warning]
This document describes installation know-how of
information displays for our business partners.
Please be careful not to distribute this document
or part of its contents to other companies, or
divert (use) it for competitors’ models.
Please also be reminded that numerical values
and expressions in this document are subject to
change according to future evaluation without
prior notice.

Sharp PN-CD701 Specifications

General

Response time	6 ms
Display diagonal	70 \
Display brightness	350 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (typical)	4000:1
Display number of colors	1.06 billion colors
Display diagonal (metric)	176.6 cm
Viewing angle, horizontal	176 °
Number of simultaneous touchpoints	10
RMS rated power	24 W
Number of built-in speakers	2
Wi-Fi	-
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	5
Windows operating systems supported	Windows 10
AC input voltage	100-240 V
Heat dissipation	801 BTU/h
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	370 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	CE, CB
Sustainability certificates	RoHS
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	41 mm
Placement supported	Indoor
Bezel width (bottom)	53 mm
Panel mounting interface	400 x 400 mm
Purpose	Corporate
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	90 mm
Width	1623 mm
Height	976.4 mm
Weight	65000 g
