PN-HB851/HB751/HB651/HM851/HM751/HM651 Installation Guidelines <Rev1.0> April. 2019
Confidential
Power Supply and Voltage
Circuit breaker
box
Monitor
Monitor
Monitor
Monitor
Circuit A
Circuit B
2.7 Power supply precautions
- This monitor are designed to be used under commercial 100V-240V power
supply, but shortage of power supply may occur in wall video installation.
- Arrange plural circuit and level power consumption in each circuit.
- Avoid over power consumption such as by delaying the wake-up time
using power-on delay function.
12
