30
E
Others
Function
Command Direction
Parameter Reply Control/Response contents *
VOLUME VOLM WR 0-31 0-31
-
MUTE AUDIO MUTE WR 0-1 0-1 0: OFF, 1: ON
Temperature sensor DSTA R 0 Internal temperature normal
●
1 Internal temperature abnormal has occurred and the monitor is in standby state
2 Internal temperature abnormal occurred (To delete the information of temperature
abnormal, turn o the main power.)
3 Internal temperature abnormal has occurred and backlight brightness is dimmed
4 Temperature sensor abnormal
Temperature acquisition ERRT R Value Returns the temperature at the temperature sensors.
Indicates a temperature sensor abnormality when “126” is returned.
-
Check the resolution PXCK R - Returns current resolution in the form of hhh, vvv.
Controlling the Monitor with a computer (RS-232C)
