MOUNTING PRECAUTIONS
• Thisproductisforuseindoors.
• AmountingbracketcompliantwithVESAspecicationsis
required.
• Sincethemonitorisheavy,consultyourdealerbefore
installing,removingormovingthemonitor.
• Mountingthemonitoronthewallrequiresspecialexpertise
andtheworkmustbeperformedbyanauthorizedSHARP
dealer.Youshouldneverattempttoperformanyofthis
workyourself.Ourcompanywillbearnoresponsibility
foraccidentsorinjuriescausedbyimpropermountingor
mishandling.
• Thismonitorcannotbeusedinverticalorientation.
• Usethemonitorwiththesurfaceperpendiculartoalevel
surface.Ifnecessary,themonitormaybetiltedupto20
degreesupward.
• Whenmovingthemonitor,besuretoholditwitheither
handlesorthecornersonthebottomoftheunit.Donot
placeyourhandonthescreen.Thismaycauseproduct
damage,failure,orinjury.
• Thismonitorshouldbeusedatanambienttemperature
between41°F(5°C)and95°F(35°C).Provideenough
spacearoundthemonitortopreventheatfrom
accumulatinginside.
7-7/8 [20]
Unit: inch [cm]
2 [5]
2
[5]
2
[5]
1-7/16 [3.5]
• Ifitisdifculttoprovidesufcientspaceforanyreason
suchastheinstallationofthemonitorinsideahousing,or
iftheambienttemperaturemaybeoutsideoftherange
of41°F(5°C)to95°F(35°C),installafanortakeother
measurestokeeptheambienttemperaturewithinthe
requiredrange.
• Temperatureconditionmaychangewhenusingthemonitor
togetherwiththeoptionalequipmentsrecommendedby
SHARP.Insuchcases,pleasecheckthetemperature
conditionspeciedbytheoptionalequipments.
• Donotblockanyventilationopenings.Ifthetemperature
insidethemonitorrises,thiscouldleadtoamalfunction.
• Donotplacethemonitoronadevicewhichgeneratesheat.
• Donotusetheproductinlocationswheretheunitis
exposedtodirectsunlightorotherstronglight.Sincethis
productoperateswithinfraredrays,suchlightmaycausea
malfunction.
• FixtheUSBcablewiththecableclamp(supplied).
(1) Coilthecableintotwoloopsapprox.1-9/16inches
(4cm)indiameteratapprox.5-7/8inches(15cm)
fromtheminiUSBconnector.
(2) FixtheloopstothexingpartabovetheUSBportwith
thecableclamp.
(2)
(1)

Sharp PN-L602B Specifications

General

Dimensions (WxDxH)	1440 x 101 x 855 mm
Ethernet LAN (RJ-45) ports	1
Display viewable area (HxV)	1329.1 x 747.6 mm
3D	No
Pixel pitch	0.692 x 0.692 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	60 \
Separate H/V sync	Yes
Display brightness	300 cd/m²
Contrast ratio (typical)	3000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	152.5 cm
Viewing angle, horizontal	160 °
Product color	Gray
Compatible operating systems	Windows XP, Windows Vista, Windows 7
Cables included	AC, USB
RS-232 ports	2
AC input voltage	110 - 240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	165 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
RMS rated power	14 W

Weight and Dimensions

Weight (without stand)	54000 g
