RS-232C command table
How to read the command table
Command: Command field (See page 51.)
Direction: W When the “Parameter” is set in the parameter field (see page 51), the command functions as described
under “Control/Response Contents”.
R The returned value indicated under “Reply” can be obtained by setting “????” or “
?” in the
parameter field. (See page 51.)
Parameter: Parameter field (See page 51.)
Reply: Response (Returned value)
* : “●” : Indicates a command which can be used in standby state, input signal waiting state or when the
power is on.
“○” : Indicates a command which can be used in input signal waiting state or when the power is on.
“ ” : Indicates a command which can be used in standby state or when power is on.
“–” : Indicates a command which can be used when the power is on.
Power control/Input mode selection
Function Command Direction Parameter Reply Control/Response contents *
Power control POWR W 0 Switches to standby state.
●
1 Returns from standby state.
R 0 Standby state
1 Normal mode
2 Input signal waiting state
Input mode selection INPS W 0 Toggle change for input mode.
○
WR 2 D-SUB
10 HDMI1
13 HDMI2
18 HDMI3
21 OPTION
24 APPLICATION
27 USB-C
Common Settings menu
Function Command Direction Parameter Reply Control/Response contents *
Volume VOLM WR 0-100 0-100
-
Mute MUTE WR 0-1 0-1 0: Off, 1: On
Size (Screen size selection) WIDE WR 1-3 1-3 1: Wide, 2: Normal, 3: Dot by Dot
Auto ASNC W 1 When the input mode is D-SUB.
Color Mode BMOD WR 0 0 Standard
4 4 High Illuminance
8 8 Custom
White balance WHBL WR 0-3 0-3 0:Thru, 1:Standard, 2:Warm, 3:Lamp
Administrator Settings menu
Function Command Direction Parameter Reply Control/Response contents *
Date & Time Settings DATE WR
AABBCCDDEE AABBCCDDEE AA: Year, BB: Month, CC: Day, DD: Hour, EE: Minute -
Model INF1 R Value
Serial no. SRNO R Value
