Sharp PRO-60X5FD - Chapter 1. Specifications; Specifications

PRO-60/70X5FD
1 – 1
PRO60X5FD
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item Model: PRO-70X5FD Model: PRO-60X5FD
LCD
panel
Size 70" Class (69
1
/
2
" Diagonal)
60" Class (60
1
/
32
" Diagonal)
Resolution 2,073,600 pixels (1,920
1,080)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
*1
(64/256 QAM)
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
Audio out 15W 2 + 15 W (WF)
Terminals
Back panel
vertical
inputs
HDMI 1 HDMI in with HDCP, Audio in (Ø 3.5 mm stereo jack)
HDMI 2 HDMI in with HDCP
HDMI 3 HDMI in with HDCP
HDMI 4 HDMI in with HDCP
HDMI 5 HDMI in with HDCP
AUDIO OUT Audio out (Ø 3.5 mm stereo jack)
USB 1
*2
Photo/Music/Video mode, Software update
Back panel
surface
inputs
COMPONENT COMPONENT in
VIDEO 1 AV in
VIDEO 2 AV in
PC IN
ANALOG RGB (PC) in (15-pin mini D-sub female connector),
Audio in (Ø 3.5 mm stereo jack)
RS-232C 9-pin D-sub male connector
Back panel
horizontal
inputs
ANT/CABLE
75 Unbalance, F Type 1 for Analog (VHF/UHF/CATV) and Digital (AIR/CABLE)
AUDIO IN Audio in (Ø 3.5 mm stereo jack)
DIGITAL AUDIO OUTPUT Optical Digital audio output 1 (PCM/Dolby Digital)
ETHERNET Network connector
USB 2 Photo/Music/Video mode, Software update
OSD language English/French/Spanish
Power Requirement AC 120 V, 60 Hz
Power Consumption
282 W (0.13 W Standby with AC 120 V) 204 W (0.1 W Standby with AC 120 V)
Weight
TV + stand 101.4 lbs./46.0 kg 71.7 lbs./32.5 kg
TV only 94.8 lbs./43.0 kg 66.1 lbs./30.0 kg
Dimension
*3
(W H D)
TV + stand 63
61
/
64
40
3
/
64
13
1
/
8
inch 55
1
/
8
34
13
/
16
13
1
/
8
inch
TV only 63
61
/
64
38
43
/
64
3
1
/
32
inch 55
1
/
8
33
7
/
16
3
1
/
32
inch
Operating temperature
+32°F to +104°F (0°C to +40°C)
*1
Emergency alert messages via Cable are unreceivable.
*2
Skype will be available only for the USB 1 terminal. For details, refer to the following:
For Skype information (http://www.skype.com)
For Operating Instructions (http://www.elitelcdtv.com)
*3
The dimensional drawings are shown on the inside back cover.
As part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of production
units. There may be some deviations from these values in individual units.
