Sharp R-211(W)M - Parts List

17
211M -
Note: The parts marked “ * ” are used in voltage more than 250V. The parts marked ∆ may cause undue microwave exposure
“§” MARK: SPARE PARTS-DELIVERY SECTION
ELECTRICAL PARTS
REF NO PART NO S DESCRIPTION Q'TY CODE
1-1 RH-DZA048WRE0 U H.V. rectifier 1 AM *
1-2 FPWBFA308WRE1 U Noise filter 1 AQ
1-3 QACCBA030WRE2 U Power supply cord 1 AQ
1-4 RV-MZA270WRE0 U Magnetron 1 BG *∆
1-5 RC-QZA221WRE0 U High voltage capacitor 1 AT
1-6 QSW-MA110WRE0 J Monitored latch switch/Stop switch 2 AK
1-7 QSW-MA112WRE0 J Monitor swith 1 AN
1-8 RMOTEA360WRE0 U Fan motor 1 AU
1-9 QFS-CA024WREO U Fuse F8A 1 AC
1-10 RLMPTA066WRE0 U Oven lamp 1 AK
1-11 FMOTDA056WRKO J Turntable motor assy 1 AR
1-13 RTHM-A096WRE0 U Thermal cut-out 125°C (Oven) 1 AL
1-14 RTRN-A009UREO U Power transformer 1 BH *
PART LIST
CABINET PARTS
REF NO PART NO S DESCRIPTION Q'TY CODE
2-1 GCABUA001URP0 U Outer case cabinet (B) 1 AT ∆
2-1 GCABUA573WRT0 U Outer case cabinet (W) 1 AT ∆
2-1 GCABUA003URP0 U Outer case cabinet (G) 1 AT ∆
2-1 GCABUA009URP0 U Outer case cabinet (BL) 1 AT ∆
2-2 GLEGPA057WRE0 U Foot 2 AB
CONTROL PANEL PARTS
REF NO PART NO S DESCRIPTION Q'TY CODE
3- 1 DPWBFB785WRK0 J Control unit 1
3- 1A QCNCMA430DRE0 J 3-pin connector (CN-A) 1 AG
3- 1B QCNCMA414DRE0 J 2-pin connector (CN-B) 1 AB
3- 1C FW-VZA234DRE0 J Lead wire (WH-A) 1 AD
3- 1D LHLD-A004URF0 J LED holder 1 AC
C1 VCEAB31VW477M J Capacitor 470 uF 35V 1 AC
C2 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AA
C3 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AA
C4 VCEAB31CW476M J Capacitor 47 uF 16V 1 AA
C5 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AA
C6 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AA
C20 VCEAB31HW104M J Capacitor 0.1 uF 50V 1 AM
C21 VCEAB31VW106M J Capacitor 10 uF 35V 1 AA
C30 VCKYD11CY103N J Capacitor 0.01 uF 16V 1 AA
C60-61 VCKYD11CY103N J Capacitor 0.01 uF 16V 2 AA
CF1 RCRS-A012DRE0 J Ceramic resonator (CST4.00MGW) 1 AD
D1-4 VHD1N4005E1-2 J Diode (1N4005E) 4 AB
D5 VHD1SS270A/-1 J Diode (1SS270ATA) 1 AA
D20-22 VHD1SS270A/-1 J Diode (1SS270ATA) 3 AA
D30 VHD1SS270A/-1 J Diode (1SS270ATA) 1 AA
I-1 RH-IZA882DRE0 J LSI 1 AK
LD1-24 VHPLTL1CHE/-3 J Light emitting diode (LED) 24 AD
Q1 VS2SB1238//-3 J Transistor (2SB1238) 1 AA
Q2 VSDTA123ES/-3 J Transistor (DTA123ES) 1 AA
Q10 VS2SB1238//-3 J Transistor (2SB1238) 1 AA
Q20 VSKRA101M//-3 J Transistor (KRA101M) 1 AB
Q21 VSDTD143ES/-3 J Transistor (DTD143ES) 1 AC
Q22 VSDTA143ES/1B J Transistor (DTA143ES) 1 AA
Q40 VSKRA101M//-3 J Transistor (KRA101M) 1 AB
Q50-53 VSKRA222M//-3 J Transistor (KRA222M) 4 AB
R1 VRS-L63DA101J J Resistor 100 ohm 2W 1 AD
R4 VRD-B12HF202J J Resistor 2.0k ohm 1/2W 1 AB
R5-6 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 2 AA
R7 VRD-B12EF103J J Resistor 10k ohm 1/4W 1 AA
R10 VRD-B12HF102J J Resistor 1.0k ohm 1/2W 1 AA
