18
211M -
PART LIST
CONTROL PANEL PARTS
REF NO PART NO S DESCRIPTION Q'TY CODE
R20 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 1 AA
R30 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 1 AA
R31 VRD-B12EF473J J Resistor 47k ohm 1/4W 1 AA
R40 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
R50-55 VRD-B12EF151J J Resistor 150 ohm 1/4W 6 AA
R60-61 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 2 AA
R62-63 VRD-B12EF104J J Resistor 100k ohm 1/4W 2 AA
RY1 RRLY-A111DRE0 J Relay (JV12S-KT) 1 AL
RY2 RRLY-A105DRE0 J Relay (OMIF-S-112LM) 1 AN
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
SW1 RVR-BA018WRE0 J Rotary encoder 1 AL
T1 RTRNPA121DRE0 J Transformer 1 AT
VR1 RVR-BA013DRE0 J Potention meter 1 AF
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
ZD1 VHEHZ6A3///-1 J Zener diode (HZ6A3) 1 AC
ZD2 VHEHZ4A2///-1 J Zener diode (HZ4A2) 1 AA
ZD3 VHEHZ12A3//-1 J Zener diode (HZ12A3) 1 AA
3- 2 HPNLCG001URR0 U Control panel [R-211(G)M] 1 AP
3- 2 HPNLCL001URR0 U Control panel [R-211(BL)M] 1 AP
3- 2 HPNLCW002URR0 U Control panel [R-211(W)M] 1 AP
3- 2 HPNLCB001URR0 U Control panel print (R-211(B)M) 1 AP
3- 3 JBTN-A011URF0 U Open button [R-211(G)M] 1 AE
3- 3 JBTN-A073URF0 U Open button [R-211(BL)M] 1 AE
3- 3 JBTN-A001URF0 U Open button (R-211(B)M) 1 AE
3- 3 JBTN-B009WRF0 U Open button [R-211(W)M] 1 AE
3- 4 MSPRCA045WRE0 U Spring 2 AA
3- 5 GMADIA011URR0 U Timer display plate 1 AE
3- 6 JKNBKG001URF0 U Timer knob [R-211(G)M] 1 AE
3- 6 JKNBKL001URF0 U Timer knob [R-211(BL)M] 1 AE
3- 6 JKNBKW001URF0 U Timer knob [R-211(W)M] 1 AE
3- 6 JKNBKB001URF0 U Timer knob (R-211(B)M) 1 AE
3- 7 JKNBKG002URF0 U Vari knob [R-211(G)M] 1 AD
3- 7 JKNBKL002URF0 U Vari knob [R-211(BL)M] 1 AD
3- 7 JKNBKB002URF0 U Vari knob (R-211(B)M) 1 AD
3- 7 JKNBKW002URF0 U Vari knob (R-211(W)M) 1 AD
3- 8 LSTPPA008URF0 U Stopper 1 AB
3- 9 XEPSD30P10XS0 U Self tapping screw 5 AA
3- 10 PCLI-A001URE0 U Harness clip 1 AC
OVEN PARTS
REF NO PART NO S DESCRIPTION Q'TY CODE
4-1 DOVN-A005URT0 U Oven cavity 1 BA
4-2 LBNDKA111WRP0 U Capacitor holder 1 AD
4-3 PHOK-A092WRF4 U Latch hook 1 AH
4-4 NFANJA029WRE0 U Fan blade 1 AM
4-5 PDUC-A638WRF2 U Fan duct 1 AE
4-6 LANGFA169WRP5 U Chassis support 1 AE
4-7 PPACGA126WRE0 U Seal packing 1 AC
4-8 MLEVFA078WRF0 U Open lever 1 AE
4-9 PCOVPA309WRE0 U Waveguide cover 1 AC
4-10 PDUC-A581WRF3 U Air intake duct 1 AE
4-11 GDAI-A280WRP1 U Base plate 1 AQ
4-12 PCUSGA001URP0 U HVT cushion 1 AB
4-13 PSPAGA001WRE0 U Vibration Proof Cushion 1 AA
