19
211M -
Note: The parts marked “*” are used in voltage more than 250V. The parts marked ∆ may cause undue microwave exposure
“§” MARK: SPARE PARTS-DELIVERY SECTION
DOOR PARTS
REF NO PART NO S DESCRIPTION Q'TY CODE
5 CDORFB001URK0 U Door assembly (B) 1 BB ∆
5 CDORFW001URK0 U Door assembly (W) 1 BB ∆
5 CDORFG002URK0 U Door assembly (G) 1 BB ∆
5 CDORFL001URK0 U Door assembly (BL) 1 BB ∆
5-1 FDORFA299WRT0 U Door panel assembly 1 AU
5-2 GCOVHA366WRF0 U Choke cover 1 AG
5-3 GWAKPA001URF0 U Door frame (B) 1 AP ∆
5-3 GWAKPA427WRF0 U Door frame (W) 1 AP ∆
5-3 GWAKPA009URF0 U Door frame (G) 1 AP ∆
5-3 GWAKPA025URF0 U Door frame (BL) 1 AP ∆
5-4 PSHEPA560WRE1 U Outer sealer film 1 AE
5-5 LSTPPA158WRF0 U Latch head 1 AD
5-6 MSPRTA141WRE0 U Latch spring 1 AA
5-7 PSHEPA482WRE0 U Inner Sealer film 1 AH
5-8 XEBSD30P06000 U Self tapping screw 4 AA
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
PART LIST
MISCELLANEOUS
REF NO PART NO S DESCRIPTION Q'TY CODE
6-1 FROLPA070WRK2 U Roller stay 1 AM
6-2 NTNT-A034WRF0 U Turntable 1 AN
6-3 TINS-A069URRO U Operation Manual/Cookery book 1 AM
6-4 QW-QZA191WRE0 U H.V. wire A 1 AF *
6-5 QW-QZA001URE0 U H.V. wire B 1 AE *
6-6 FW-VZA041UREO U Main wire harness 1 AR
SCREW, NUT AND WASHER
REF NO PART NO S DESCRIPTION Q'TY CODE
7-1 XOTSD40P12RV0 J Screw 4mm x 12mm 12 AA
7-2 XHTSD40P08RV0 J Screw 4mm x 8mm 5 AA
7-3 LX-LZA011WRE0 U Rivet 1 AB
7-4 Not applicable to this model
7-5 XFPSD40P06000 J Screw 4mm x 8mm 2 AA
7-7 XOTSE40P12000 J Screw 4mm x 12mm (Chrome) 2 AA
7-7 XOTSF40P12000 J Screw 4mm x 12mm (Black) 2 AA
7-8 LX-CZA063WRE0 U HVT screw 4 AA
7-9 XHPSD40P08K00 J Screw 1 AA
7-10 LX-CZA030WRE0 J Screw 1 AA
7-11 LX-NZA026WRE0 U M4 Nyloc nut 1 AA
7-12 XOTSD40P10000 J Self tapping screw 2 AA
To Next Page
