Sharp R-239 Service Manual

R239(W)
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
ELECTRIC PARTS
1-1 QACC-A075WRE0 AW
Power supply cord
!
1-2 FH-DZA115WRKZ AR
High voltage rectifier assy
1-3 FPWBFA387WRKZ AW
Noise filter
!
C RC-QZA295WRZZ AV
High voltage capacitor
!
C RC-QZA218WRE0 AW
High voltage capacitor (Interchangeable)
F1 QFS-CA027WRZZ AG
Fuse T6.3A
!
F2 QFS-IA004WRE0 AK
High voltage fuse 0.6A
FM RMOTEA405WRZZ AX
Fan motor
FM RMOTEA390WRE0 AW
Fan motor (Interchangeable)
!
*
MG RV-MZA341WRZZ BG
Magnetron
OL RLMPTA083WRZZ AM
Oven lamp
SW1 QSW-MA085WRE0 AF
1st. Latch switch
SW1 QSW-MA137WRE0 AH
1st. Latch switch (Interchangeable)
SW1 QSW-MA147WRZZ AG
1st. Latch switch (Interchangeable)
SW2 QSW-MA086WRE0 AF
Monitor switch
SW2 QSW-MA138WRE0 AH
Monitor switch (Interchangeable)
SW2 QSW-MA148WRZZ AF
Monitor switch (Interchangeable)
SW3 QSW-MA085WRE0 AF
2nd. Interlock relay control switch
SW3 QSW-MA137WRE0 AH
2nd. Interlock relay control switch (Interchangeable)
SW3 QSW-MA147WRZZ AG
2nd. Interlock relay control switch (Interchangeable)
!
T RTRN-A734WRZZ BM
High voltage transformer
TF QFS-TA014WRE0 AG
Temperature fuse 150C (Oven)
TTM RMOTDA265WRZZ AS
Turntable motor
TTM RMOTDA173WRE0 AX
Turntable motor (Interchangeable)
TTM RMOTDA253WRZZ AV
Turntable motor (Interchangeable)
CABINET PARTS
2-1 GCABUA958WRPZ BE
Outer case cabinet [R-239(W)]
2-1 GCABUA966WRPZ BE
Outer case cabinet [R-239(IN)]
2-2 GDAI-A377WRWZ AS
Bottom plate
2-3 GLEGPA104WREZ AF
Foot
OVENPARTS
*
4-1 PHOK-A146WRFZ
Latch hook
4-2 LBNDKA168WRPZ AD
Capacitor holder
4-3 NFANJA053WRFZ AG
Fan blade
4-4 PDUC-A908WRWZ AR
Fan duct
*
4-5 FOVN-A551WRTZ BG
Oven cavity
4-6 LANGFA267WRPZ AH
Chassis support
4-7 PSPAJA007WRFZ AF
Spacer
4-8 PCOVPA419WREZ AG
Waveguide cover
4-9 PDUC-A909WRPZ AN
Air duct
4-10 PPACGA176WREZ AC
TTM packing
4-11 PCUSUA501WRP0 AB
Cushion
4-12 PCUSGA664WREZ AF
Cushion C
MISCELLANEOUS
6-1 NTNT-A034WRF0 AM
Turntable
6-2 FROLPA101WRKZ AR
Turntable support
6-3 TCAUHA168WRR0 AH
H caution label
SCREWS,NUTS AND WASHERS
7-1 XHPS740P08K00 AB
Screw : 4mm x 8mm
7-2 XEPS740P10000 AA
Screw : 4mm x 10mm
7-3 XHPS740P08000 AB
Screw : 4mm x 8mm
7-4 LX-CZ0052WRE0 AA
Special screw
7-5 LX-EZA042WRE0 AB
Special screw
7-6 LX-CZA073WRE0 AC
Special screw
7-7 XHTS740P08RV0 AG
Screw : 4mm x 8mm
7-8 XOTS740P08000 AA
Screw : 4mm x 8mm
7-9 XOTS740P12RV0 AD
Screw : 4mm x 12mm
7-10 XOTS740P12000 AA
Screw : 4mm x 12mm
