R239(W)
3 – 1
R239(W)
Service Manual
CHAPTER 3. PRODUCT SPECIFICATIONS
TEM DESCRIPTION
Power Requirements
230 Volts
50 Hertz
Single phase, 3 wire earthed
Power Consumption 1.25 kW
Power Output
800 watts nominal of RF microwave energy (IEC60705 Test Procedure)
Operating frequency 2450 MHz
Case Dimensions
Width 460 mm
Height 275 mm including foot
Depth 380 mm
Cooking Cavity Dimensions
Width 319 mm NOTE: Internal capacity is calculated by measuring maximum width, depth and height.
Height 211 mm Actual capacity for holding food is less.
Depth 336 mm
Turntable diameter 272 mm
Control Complement
Touch Control System
Timer (0 - 99 minutes 90 seconds)
Clock (1:00 - 12:59) or (0:00 - 23:59)
Microwave Power for Variable Cooking
Repetition Rate;
100P ....................................................... Full power throughout the cooking time
70P .........................................................approx. 70% of FULL Power
50P ....................................................... approx. 50% of FULL Power
30P ........................................................approx. 30% of FULL Power
10P .........................................................approx. 10% of FULL Power
EXPRESS COOK & DEFROST button
MICROWAVE POWER LEVEL button
STOP button
START/+1 min button
TIMER/WEIGHT knob
Set Weight (Approx.) 12 kg
