Sharp R-239 Service Manual

R239(W)
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PARTS
3-1 DPWBFC487WRUZ BH
Control unit
3-2 DPWBFC494WRKZ BF
Switch unit
3-3 GMADIA144WRFZ AG
Display window
3-4 HPNLCB933WRRZ AT
Control panel [R-239(W)]
3-4 HPNLCB935WRRZ AU
Control panel [R-239(IN)]
3-5 JBTN-B321WRRZ AH
Select button [R-239(W)]
3-5 JBTN-B318WRRZ AK
Select button [R-239(IN)]
3-6 JKNBKA729WRFZ AG
Timer knob [R239(W)]
3-6 JKNBKA730WRTZ AG
Timer knob [R239(IN)]
3-7 XEPS730P08XS0 AA
Screw; 3mm x 8mm
3-8 PCUSUA173WRP0 AC
Cushion
DOOR PARTS
*
5-1 FDORFA397WRTZ BB
Door panel assembly
*
5-2 GWAKPA995WRFZ AW
Door frame [R-239(W)]
*
5-2 GWAKPA996WRTZ AX
Door frame [R-239(IN)]
5-3 JHNDMA045WRTZ AP
Door handle [R-239(W)]
5-3 JHNDMA047WRTZ AP
Door handle[R-239(IN)]
*
5-4 LSTPPA211WRFZ AG
Latch head
5-5 LSTPPA231WRFZ AG
Glass stopper
5-6 MSPRTA187WRE0 AC
Spring
5-7 PGLSPA633WREZ AR
Door glass
5-8 PSHEPA782WREZ AG
Sealer film
*
5-9 GCOVHA424WRFZ AK
Choke cover
5-10 XEPS740P10000 AA
Screw : 4mm x 10mm
MISCELLANEOUS
6-4 TINSZA133WRRZ AP
Instruction book
6-5 FW-VZC056WREZ AQ
Main wire harness
6-6 FW-VZB888WREZ AU
Switch harness

Sharp R-239 Specifications

General

Brand	Sharp
Model	R-239
Category	Microwave Oven
Language	English
