Sharp R-244(W)M - Page 24

24
R-244M -
Note: The parts marked ”*” are used in voltage more than 250V. The parts marked ∆ may cause undue microwave exposure
“§” MARK: SPARE PARTS-DELIVERY SECTION
4-1 DOVN-A013URT1 U Oven cavity 1 BA
4-2 GDAI-A280WRP1 U Base plate 1 AQ
4-3 LBNDKA111WRP0 U H.V.Capacitor holder 1 AD
4-4 PHOK-A001URF1 U Latch hook 1 AH
4-6 PDUC-A638WRF2 U Fan duct 1 AE
4-7 NFANJA029WRE0 U Fan blade 1 AM
4-8 LANGFA169WRP6 U Chassis support 1 AE
4-9 PPACGA002URE0 U Packing seal 1 AB
4-10 PCOVPA309WRE0 U Waveguide cover 1 AC
4-11 PDUC-A581WRF3 U Air intake duct 1 AE
4-12 PCUSGA308WRP0 U HVT cushion Not on BOM 2 AA
4-13 PSPAGA001WRE0 U Vibration Proof Cushion 1 AA
PARTS LIST
REF NO. PART NO. § DESCRIPTION Q'TY CODE
CONTROL PANEL PARTS (CONTINUED)
OVEN PARTS
R31 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R40 VRD-B12HF152J U Resistor 1.5k ohm 1/2W 1 AA
R41 VRD-B12EF102J U Resistor 1.0k ohm 1/4W 1 AA
R42 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R50 VRN-B12EK103F U Resistor 10k ohm 1/4W 1 AA
R64 VRD-B12EF104J U Resistor 100k ohm 1/4W 1 AA
R70-71 VRS-B13AA361J U Resistor 360 ohm 1W 2 AA
R72 VRD-B12EF822J U Resistor 8.2k ohm 1/4W 1 AA
R73 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R80 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R81 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
RW VRD-B12EF104J U Resistor 100k ohm 1/4W 1 AA
RY1 RRLY-A080DRE0 U Relay (OJ-SH-124LM) 1 AG
RY2 RRLY-A105DRE0 U Relay (OMIF-S-112LM) 1 AG
SP30 RALM-A014DRE0 U Buzzer (PKM22EPT-THAI) 1 AG
VRS1 RH-VZA032DRE0 U Varistor (10G471K) 1 AC
ZD1 VHEHZ12C1//-1 U Zener diode (HZ12C1) 1 AA
ZD20-21 VHEHZ12C1//-1 U Zener diode (HZ12C1) 2 AA
ZD40 VHEHZ4C3///-1 U Zener diode (HZ4C-3) 1 AA
ZD70-71 VHEHZ7C2///-1 U Zener diode (HZ7C2) 2 AA
3- 2 FPWBFA058URK0 U Switch unit assembly 1 AW
3- 2-1 FW-VZA262DRZZ U 6-pin harness (CN-C) 1 AE
3- 2-2 QSW-PA016DRE0 U Tact switch (SW1-8) 8 AB
3- 3 HPNLCB034URR0 U Control panel frame [R-244(B)M] 1 AK
3- 3 HPNLCG024URR0 U Control panel frame [R-244(G)M] 1 AK
3- 3 HPNLCS030URR0 U Control panel frame [R-244(SL)M] 1 AV
3- 3 HPNLCW071URR0 U Control panel frame [R-244(W)M] 1 AK
3- 4 GCOVHA032URF0 U Key fixing frame 1 AF
3- 5 GMADIA006URF0 U Display window 1 AF
3- 6 PSHEPA045URE0 U Key sheet [R-244(W)M] 1 AM
3- 6 PSHEPA046URE0 U Key sheet [R-244(G)M] 1 AM
3- 6 PSHEPA047URE0 U Key sheet [R-244(B)M] 1 AM
3- 6 PSHEPA048URE0 U Key sheet [R-244(SL)M] 1 AM
3- 7 XEPSD30P10XS0 U Screw; 3mm x 10mm 7 AA
