3
4
2
1
5
6
7
8
2
OVEN AND ACCESSORIES
9
10
11
1 Control Panel
2 Oven Lamp
3 Door opening button
4 Waveguide cover
5 Coupling
6 Oven cavity
7 Door seals and sealing
surfaces
8 Door latches
9 Ventilation openings
10 Outer cabinet
11 Power cord
12
13
14
ACCESSORIES:
Check to make sure the following accessories
are provided:
12 Turntable 13 Turntable support 14 Coupling
Place the turntable support in the centre of the oven
floor so that it can freely rotate around the coupling.
Place the turntable onto the turntable support so that
it locates firmly into the coupling.
To avoid turntable damage, ensure dishes or
containers are lifted clear of the turntable rim when
removing them from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your dealer
or SHARP authorised service agent.
