33
R-360EG
R-360ES
R-360EW
R-360EZ
*
*
*
*
∆
*
∆
*
∆
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 FACCDA085WREZ Power supply cord 1 AQ
1- 2 QFSHDA024WRZZ Fuse holder 1 AG
1- 3 QSW-MA137WRE0 Primary interlock switch / door sensing switch 2 AH
1- 4 FFS-BA023WRK0
Monitor fuse 20A and monitor switch (AM51620C53Y1) assembly
1AS
1- 5 RTHM-A116WRE0 Thermal cut-out 125 deg. C (MG) 1 AK
1- 6 FH-DZA100WRKZ High voltage rectifier assembly 1 AQ
1- 7 RC-QZA211WRE0 High voltage capacitor 1 AV
1- 7 RC-QZA286WRZZ High voltage capacitor (Interchangeable) 1 AV
1- 8 RMOTEA400WRZZ Fan motor 1 AX
1- 9 RTRN-A638WRZZ Power transformer 1 BP
1-10 RV-MZA288WRE0 Magnetron 1 BK
1-10 RV-MZA308WRZZ Magnetron (Interchangeable) 1 BL
1-11 RLMPTA082WRZZ Oven lamp 1 AL
1-12 RMOTDA186WRE0 Turntable motor 1 AW
1-12 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1-13 RTHM-A123WRZZ Thermal cut-out 125 deg. C (OVEN) 1 AK
CABINET PARTS
2- 1 GDAI-A335WRWZ Base plate 1 AW
2- 2 GCOVAA290WRFZ Front cover 1 AM
2- 3 GLEGPA081WRFZ Leg 1 AC
2- 4 GCABUA803WRPZ Outer case cabinet [R-360ES] 1 BD
2- 4 GCABUA805WRPZ Outer case cabinet [R-360EW] 1 BD
2- 4 GCABUA807WRPZ Outer case cabinet [R-360EZ] 1 BD
2- 4 GCABUA809WRPZ Outer case cabinet [R-360EG] 1 BD
POWER UNIT PARTS
3- 1 DPWBFC174WRUZ Power unit 1 BE
3- 1A QCNCMA431DRE0 2-pin connector (CN-B) 1 AC
3- 1B QCNCMA469DRZZ 7-pin connector (CN-C) 1 AE
C1 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31EW108M Capacitor 1000 uF 25V 1 AE
C21 VCEAB31VW106M Capacitor 10 uF 35V 1 AA
D1-4 RH-DZA006PRE0 Diode (1N4002) 4 AD
D20-22 VHD1SS270A/-1 Diode (1SS270A) 3 AA
D40 VHD1SS270A/-1 Diode (1SS270A) 1 AA
Q21 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
Q22 VSDTA143ES/1B Transistor (DTA143ES) 1 AA
R4 VRD-B12EF332J Resistor 3.3k ohm 1/4w 1 AA
RY1 RRLY-A094DRE0 Relay (OMIF-S-112LM) 1 AN
RY2 RRLY-A114DRE0 Relay (DU12D1-1P(M)-R) 1 AN
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA110DRE0 Transformer 1 AP
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
OVEN PARTS
4- 1 PHOK-A118WRFZ Latch hook 1 AH
4- 2 LBNDKA099WRW0 Capacitor holder 1 AD
4- 3 PDUC-A772WRWZ Fan duct 1 AN
4- 4 NFANJA047WREZ Fan blade 1 AL
4- 5 PPACGA084WRF0 TTM packing 1 AE
4- 6 ************* Oven cavity (Not a replaceable part) 1--
4- 7 GCOVHA423WRFZ Choke cover 1 AL
4- 8 LANGQA531WRWZ Lamp angle 1 AP
4- 9 PCOVPA361WREZ Waveguide cover 1 AD
4-10 LANG-A084WRFZ Separate angle A 1 AG
4-11 LANG-A085WRFZ Separate angle B 1 AG
4-12 LANG-A086WRFZ Separate angle C 1 AG
4-13 PCLI-A002WREZ PC support clip 1 AD
4-14 FANG-A013WRYZ Magnetron duct assembly 1 AP
4-15 LANGFA200WRPZ Support angle 1 AD
4-16 NCPL-A053WRFZ Coupling 1 AE
4-17 PCUSUA571WRPZ Cushion 1 AH
4-18 PDUC-A771WRTZ Exhaust duct 1 AQ
4-19 PPACGA181WREZ Cushion 1 AH
4-20 PPACGA182WREZ Cushion 1 AC
4-21 PCUSUA573WRPZ Cushion 1 AC
To Next Page
