Sharp R-64ST Service Manual

R-64ST - 40
Note: The parts marked ”*” are used in voltage more than 250V. The parts marked ∆ may cause undue microwave exposure
“§” MARK: SPARE PARTS-DELIVERY SECTION
PARTS LIST
4-1 DOVN-A006URK1 U Oven cavity 1 BE
4-2 LBNDKA111WRP0 U Capacitor holder 1 AD
4-3 PHOK-A001URF1 U Latch hook 1 AH
4-4 NFANJA029WRE0 U Fan blade 1 AM
4-5 PDUC-A638WRF2 U Fan duct 1 AE
4-6 LANGFA169WRP6 U Chassis support 1 AE
4-7 PPACGA002URE0 U Seal packing 1 AB
4-8 PCUSUA340WRP2 U Separate cushion A 1 AA
4-9 PCOVPA309WRE0 U Waveguide cover 1 AC
4-10 PDUC-A581WRF3 U Air intake duct 1 AE
4-11 GDAI-A280WRP1 U Base plate 1 AQ
4-12 PSPAGA001WRE0 U Vibration Proof Cushion 1 AA
REF NO. PART NO. § DESCRIPTION Q'TY CODE
5 CDORFS016URK0 U Door assembly (SUS) 1 BG
5-1 FDORFA299WRT1 U Door panel assembly 1 AU
5-2 FWAKPS017URK0 U Door frame assy 1 BE
5-3 GWAKPR013URF0 U Door frame painted 1 AM
5-4 PGLSPA013URE0 U Outer door glass 1 AM
5-5 LSTPPA013URF0 U Latch head 1 AD
5-6 MSPRTA141WRE0 U Latch spring 1 AA
5-7 PSHEPA482WRE0 U Inner Sealer film 1 AH
5-8 LSTPPA020URF1 U Glass stopper 1 AB
5-9 XEBSD30P06000 U Door Frame screw 4 AA
5-10 JHNDPS002URT0 U Handle painted 1 AW
5-11 XEPSD30P10XS0 U Handle/glass stopper screw 2 AA
5-12 HDECQS002URP0 U Door decoration (SUS) 1 AR
5-13 GCOVHA366WRF0 U Choke cover 1 AG
CONTROL PANEL PARTS (CONTINUED)
OVEN PARTS
DOOR PARTS
R32 VRD-B12EF103J U Resistor 10k ohm 1/4W 1 AA
R40 VRD-B12EF332J U Resistor 3.3k ohm 1/4W 1 AA
R50-51 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 2 AA
R52-53 VRD-B12EF104J U Resistor 100k ohm 1/4W 2 AA
R61-62 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 2 AA
RY1 RRLY-A080DRE0 U Relay (OJ-SH-124LM) 1 AG
RY2 RRLY-A118DRE0 U Relay (DU18D1-1PR(M)) 1 AG
RY3 RRLY-A122DRE0 U Relay (DU18D1-1P(M)-R-S) 1 AG
SP1 RALM-A014DRE0 U Buzzer (PKM22EPT-THAI) 1 AG
SW50 RVR-BA018WRE0 U Encoder 1 AH
T1 RTRNPA112DRE0 U Transformer 1 AP
VRS1 RH-VZA034DRE0 U Varistor (10G471K) 1 AD
ZD1 VHEHZ5C2///-1 U Zener diode (HZ5C2) 1 AB
ZD2 VHEHZ4A2///-1 U Zener diode (HZ4A2) 1 AB
ZD20 VHEHZ201///-1 U Zener diode (HZ20-1) 1 AB
3- 2 FPWBFA053URK0 U Key switch assy 1 BC
3- 3 HPNLCS035URT0 U Control panel painted 1 AV
3- 4 GMADIA035URR0 U Display window printed 1 AH
3- 5 JBTN-S009URT0 U Select button painted 1 AE
3- 6 JKNBKS001URT0 U Rotary knob painted 1 AH
3- 7 HDECQA009URR0 U C/P decoration printed 1 AE
3- 8 XEPSD30P10XS0 U Screw; 3mm x 10mm 8 AA
3- 9 DPNLCS048URK0 U Control panel C/P assy A 1 AZ
R64ST_S.MANUAL 12/8/01, 11:01 am40
