R-64ST - 7
CAUTION
MICROWAVE RADIATION
Service engineers should not be exposed to the
microwave energy which may radiate from the magnetron
or other microwave generating devices if it is improperly
used or connected. All input and output microwave
connections, waveguides, flanges and gaskets must be
secured. Never operate the device without a microwave
energy absorbing load attached. Never look into an open
waveguide or antenna while the device is energized.
SPECIFICATION
ITEM DESCRIPTION
Power Requirements 230 Volts
50 Hertz
Single phase, 3 wire earthed
Power Consumption Microwave cooking 1.25 W Approx. 5.8 A
Grill Cooking 1050 W Approx. 4.6A
Dual Cooking 2.25W Approx. 10.1A
Power Output
800 W nominal of RF microwave energy (measured by method of IEC 60705)
Operating fequency 2450 MHz
Grill heating element Power Output (Top Grill)
1000 W (500 W x 2)
Case Dimensions Width 449 mm
Height 282 mm including foot
Depth 369mm
Cooking Cavity Dimensions Width 290 mm
Height 194 mm
Depth 313 mm
Turntable diameter 272 mm
Control Complement Jog Touch Control System
Microwave Power for Variable Cooking
Repetition Rate;
HIGH ...................................... Full power throughout the cooking time
MEDIUM HIGH ...................................... approx. 70% of FULL Power
MEDIUM ................................................ approx. 50% of FULL Power
MEDIUM LOW ....................................... approx. 30% of FULL Power
LOW ....................................................... approx. 10% of FULL Power
EXPRESS DEFROST Button
EXPRESS COOK button
STOP Button
+1 min/START button
COOKING MODE button
TIMER/WEIGHT/POWER knob
Net Weight Approx. 14 kg
WARNING
THIS APPLIANCE MUST BE EARTHED. THE WIRES IN THIS MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE:
GREEN-AND-YELLOW : EARTH BLUE : NEUTRAL BROWN : LIVE
PRODUCT DESCRIPTION
WARNING
Servicing and repair work must be carried out only by
trained service engineers.
All the parts marked "*" on parts list are used at
voltages more than 250V.
Removal of the outer wrap gives access to potentials
above 250V.
All the parts marked "∆" on parts list may cause undue
microwave exposure, by themselves, or when they
are damaged, loosened or removed.
CAUTION/WARNING
