Sharp R-64ST Service Manual

R-64ST - 39
Note: The parts marked “*” are used in voltage more than 250V. The parts marked ∆ may cause undue microwave exposure
“§” MARK: SPARE PARTS-DELIVERY SECTION
2-1 GCABUA046URP0 U Outer case cabinet (SUS) 1 AX
2-2 GLEGPA057WRE0 U Foot 2 AB
PARTS LIST
*
*
∆
*
*
*
∆
ELECTRIC PARTS
CABINET PARTS
CONTROL PANEL PARTS
3- 1 DPWBFA165URK0 U Control unit 1 BN
3- 1A QCNCMA430DRE0 U 3-pin connector (CN-A) 1 AC
3- 1B QCNCMA414DRE0 U 2-pin connector (CN-B) 1 AB
3- 1C QW-QZA003URE2 U Lead wire (WH-1, WH-2) 2 AB
3- 1D RLCDSA036DRE0 U Liquid crystal display 1 AP
3- 1E LHLD-A002URF1 U LCD holder 1 AC
3- 1F PSHEPA569WRE0 U LED sheet 1 AC
3- 1G QCNCMA151DREZ U 6-pin connector (CN-G) 1 AB
C1 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C2 VCEAG31HW477M U Capacitor 470 uF 50V 1 AA
C3 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C4-5 VCKYD41CY103N U Capacitor 0.01 uF 16V 2 AA
C6 VCEAG31HW106M U Capacitor 10 uF 50V 1 AB
C7 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C20 VCEAG31HW106M U Capacitor 10 uF 50V 1 AB
C21 RC-KZA087DRE0 U Capacitor 0.1 uF 50V 1 AB
C30 VCKYD41CY103N U Capacitor 0.01 uF 16V 1 AA
C50-51 VCKYD41CY103N U Capacitor 0.01 uF 16V 2 AA
CF1 RCRS-A012DRE0 U Ceramic resonator 1 AD
CR60 RMPTEA011DRE0 U Capacitor array 1 AG
D1-4 VHD11ES1///-1 U Diode (11ES1) 4 AB
D20-23 VHD1SS270A/-1 U Diode (1SS270ATA) 4 AA
D30 VHD1SS270A/-1 U Diode (1SS270ATA) 1 AA
IC1 RH-IXA089DRZZ U LSI 1 BA
LD1-4 VHPSLZ781C9-3 U Light emitting diode 4 AC
Q1 VSKRA101M//-3 U Transistor (KRA101M) 1 AA
Q2 VSDTA123ES/-3 U Transistor (DTA123ES) 1 AB
Q3 VS2SB1238//-3 U Transistor (2SB1238) 1 AD
Q20 VS2SB1238//-3 U Transistor (2SB1238) 1 AD
Q21-22 VSKRA223M//-3 U Transistor (KRA223M) 2 AB
Q23 VSKRC243M//-3 U Transistor (KRC243M) 1 AB
Q24 VSKRA101M//-3 U Transistor (KRA101M) 1 AA
Q40 VSKRA101M//-3 U Transistor (KRA101M) 1 AA
R1-2 VRS-B13AA511J U Resistor 510 ohm 1W 2 AB
R3-4 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 2 AA
R5 VRD-B12EF241J U Resistor 240 ohm 1/4W 1 AA
R10 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
R20 VRD-B12EF102J U Resistor 1.0k ohm 1/4W 1 AA
R21 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
R22 VRD-B12HA910J U Resistor 91 ohm 1/2W 1 AA
R30 VRD-B12EF153J U Resistor 15k ohm 1/4W 1 AA
R31 VRD-B12EF472J U Resistor 4.7k ohm 1/4W 1 AA
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
1-1 RH-DZA048WRE0 U H.V. rectifier 1 AM
1-2 RC-QZA238WRE0 U High voltage capacitor 1 AR
1-3 QSW-MA146WRZZ J Monitor switch 1 AC
1-4 QSW-MA147WRZZ J Monitored latch switch 1 AG
1-5 QSW-MA147WRZZ J Stop switch 1 AG
1-6 FPWBFA309WRE2 U Noise filter 1 AT
1-7 QFS-CA025WRE0 U Fuse F8A 1 AC
1-8 QFS-BA009WREO U Fuse 20A 1 AC
1-11 RTHM-A124WRZZ U Thermal cut-out 145°C (Oven) 1 AH
1-13 QACCVAOO4URE2 U Power supply cord 1 AQ
1-14 RMOTEA003URE0 U Fan motor 1 AQ
1-15 RV-MZA243WRE1 U Magnetron 1 BH
1-16 RLMPTA066WRE0 U Oven lamp/Socket 1 AK
1-17 RMOTDA226WRE0 U Turntable motor 1 AQ
1-18 RTRN-A018URE0 U Power transformer 1 BE
R64ST_S.MANUAL 12/8/01, 11:01 am39
