R969(W)
3 – 1
R969(W)
Service Manual
CHAPTER 3. PRODUCT SPECIFICATIONS
TEM DESCRIPTION
Power Requirements
230 Volts
50 Hertz
Single phase, 3 wire earthed
Power Consumption Microwave cooking 1.5 kW Approx 6.7A
Convection cooking 2.8 kW Approx 12.2A
Dual cooking Micro and Grill ---------------2.80kW Approx 12.4A
Micro and Convection ----- 2.95kW Approx. 13.0A
Power Output
900 watts nominal of RF microwave energy (IEC60705 Test Procedure)
Operating frequency 2450 MHz
Grill heating element Power
Output
1300W (650W x 2)
Convection heating element
Power Output
1450W
Outer Case Dimensions
Width 550 mm
Height 368 mm including foot
Depth 537 mm NOTE: The Depth does not include the door opening handle.
Cooking Cavity Dimensions
Width 375 mm NOTE: Internal capacity is calculated by measuring maximum width, depth and height.
Height 272 mm Actual capacity for holding food is less.
Depth 395 mm
Turntable diameter 362 mm
Control Complement
Touch Control System
Timer (0 - 99 minutes 90 sec.)
Clock (1:00 - 12:59) or (0:00 - 23:59)
Microwave Power for Variable Cooking
Repetition Rate;
900W ......................................... Full power throughout the cooking time
630W ........................................ approx. 70% of FULL Power
450W ....................................... approx. 50% of FULL Power
270W ........................................approx. 30% of FULL Power
90W .........................................approx. 10% of FULL Power
Convection temperature control range:
250°C, 230°C, 220°C, 200°C, 190°C, 180°C, 160°C, 130°C, 100°C and 40°C
EXPRESS DEFROST key
EXPRESS COOK key,
SENSOR COOK key
POTAO keys
INSTANT ACTION keys
LESS( )/ MORE( ) keys
LANGUAGE key, INFO key
TIME keys
GRILL key
CONVECTION key
MICROWAVE POWER LEVEL key
DUAL MODE key
WEIGHT keys
TIMER key
CLOCK SETTING key
STOP key
+ 1min key
Net Weight Approx. 23 kg
