[5] ELECTRICAL SYSTEM SPECIFICATIONS
FUNCTIONAL PART SPECIFICATIONS1.
Part Name Specifi cations Function
Fan motor F
(F fam motor)
Model No.: 4715JL-09W-S37-GF8
Rating: DC15V
Power Input: 1.05W (Vs:2.6V)
For cooling
(For freezer compartment)
Fan motor
(R fam motor)
Model No.: D08A-12PM
Rating: DC12V
Power Input: 0.84W
For cold air circulation
(For refrigerator compartment)
Fan motor g
(condenser fan motor)
Model No.: 4515JL-09W-S10-G01
Rating: DC15V
Power Input: 1.2W
For condensing
(Out side refrigerator)
D-fan motor PCI
Model No.: D09F-12SM20(EX)
Rating: DC12V 0.13A
Power Input: 1.56W
For ion releasing
(For refrigerator compartment)
Damper ass'y (R damper) 415 ± 5Ω (25°C) For refrigerator compartment temperature control
Motor Rating: DC12V 0.13A 300Ω Deodorant/bacteria elimination switching damper
Door switch
(R door switch)
5mA 5V DC
For detection of opening or closing of the door
(For refrigerator compartment)
Proximity switch
(I door switch)
DC15V 100mA 1W
For detection of opening or closing of the door
(For Ice compartment)
F proximity switch
(Freezer (bottom) door switch)
DC15V 100mA 1W
For detection of opening or closing of the door
(For freezer compartment (bottom))
Compressor
Model No.: VESD9C+
Rating: 100V 50/60Hz
Resistance value: 9.6Ω (at 25°C)
Protector
MODEL: MSP59AMN-6
Operating temperature: 120°C
For compressor overload prevention
Main PWB For main control
OP.PWB For operation panel control (touch panel)
LED PWB 15V 72mA 1.125W For refrigerator compartment illumination
Indicator PWB 3.2V 20mA 64mW
Source cord 125V 7A Source cord (2 Pin + earth)
F thermistor Resistance: 6.4kΩ (at 0°C) For detection of the freezer compartment temperature
R thermistor Resistance: 6.4kΩ (at 0°C) For detection of the refrigerator compartment temperature
DEF thermistor Resistance: 15kΩ (at 0°C) Senses when defrosting is completed
Thermo fuse
Rating: 250 V 10 A
Rated operating temperature: 77°C
For defrosting temperature excessive rise prevention
Thermistor Resistance value: 6.0kΩ (at 0°C) For detection of ice tray temperature
Gear pump Supplies water to the ice cube maker
Heater 110V 155W 78Ω For defrosting
Plasmacluter unit DC15V 34mA For bacteria elimination in compartment
Reactance 11mH±10% Class E wiring
EECON-INV PWB 100V 50/60Hz For compressor drive
Ice cube heater 12W 833Ω For making clear ice cube
Humidity sensor 0.5mA 5V DC For detection of outside temperature and humidity
Valve turret For switching refrigerant
Partition heater(R door heater) 3.4W/2910Ω For refrigerator compartment door condensation prevention
Water pipe heater 2.8W/3565Ω For water pipe freezing prevention
Tank heater 1.0W/9638Ω Avoid the water tank from freezing
V heater ass'y 9.0W/1110Ω For vegetable compartment temperature compensation
:Unexchengeable parts or Independently unexchangeable parts.
