SJPT55RHS
2 – 1
SJPT55RHS
Service Manual
CHAPTER 2. DESIGNATION OF VARIOUS PARTS
[1] EXTERNAL DESCRIPTION
The names in parenthesis “[ ]” are the denominations used in the REPLACEMENT PARTS LIST.
1. SJ-PT51R,PT55R
1. Freezer LED light [LED lamp]
2. Freezer shelf [F-shelf]
3. Movable shelf [F-shelf s]
4. Ice cube maker
5. Ice cube box [Ice storage box]
6. Control panel
7. Fresh case & door
8. Refrigerator LED light [LED Lamp]
9. Refrigerator shelf [R glass shelf ass'y]
10. Hybrid cooling panel (Aluminum panel)
11. Half shelf (1 pair)
[R galss shelf sf ass'y,
R glass shelf sb ass'y]
12. Fruit and vegetable shelf
[V glass shelf ass'y]
13. Fruit and vegetable crisper
[Vegetable case]
14. Adjustable feet & cover [Adjustable leg]
15. Magnetic door seal [Door packing]
16. Flexible pocket [F door pocket ass'y]
17. Door pocket [RF door pocket]
18. Refrigerator pocket & cover
19. Utility pocket
20. Egg holder [Egg tray]
21. Utility pocket (large)
(Only for SJ-PT55R)
22. Bottle pocket
23. Tube stand
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
23
22
17
15
