Sharp SJ-PT51R-HS Service Manual

SJPT55RHS
9 – 5
[3] R CONTOROL COVER ASSEMBLY (SJ-T51R/T55R)
1) Insert R air guider b to R air guider a. (Figure A-12)
Figure A-12
2) Fix 1) ass'y with paper tape. (Figure A-13)
3) Stick Ra-sealer a to 2) ass'y.
4) Stick Ra-sealer b to 2) ass'y.
Figure A-13
5) Stick A-sealer rc-d to Damper ass'y.
6) Insert Damper harness to Damper ass'y. (Figure A-14)
Figure A-14
R air guider a
R air guider b
R air guider b
R air guider a
R air guider b
R air guider a
R air guider b
R air guider a
R air sealer b
R air guider a
R air sealer a
R air sealer b
A-sealer rc-d
Damper harness
A-sealer rc-d
Stick A-sealer rc-d to Damper ass’y
Insert Damper harness to Damper ass’y
Damper ass’y
