PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
SM-SX100
– 1 –
INTEGRATED CIRCUITS
IC101~104 RH-IX2838AFZZ J AP Analog Amp.,IX2838AF
[110-127V]
IC101~104 VHIOPA2134/-1 J AS Analog Amp.,OPA2134
[220-240V]
IC106 VHIBP5022//-1 J AT DC/DC Converter,BP5022
IC107 VHIBP5021//-1 J AT DC/DC Converter,BP5021
IC108 VHIBA178M05T1 J AF +5V Regulator,BA178M05T
IC109 VHINJM431U/-1 J AE Regulator,NJM431U
IC201 VHINJM4558M-1 J AC Motor Driver,NJM4558M
IC202 VHIM5279L05-1 J AF Voltage Regulator,IM5279L05
IC203 VHIM5278L05-1 J AE Voltage Regulator,M5278L05
IC601 RH-IX2838AFZZ J AP Analog Amp.,IX2838AF
[110-127V]
IC601 VHIOPA2134/-1 J AS Analog Amp.,OPA2134
[220-240V]
IC651 VHINJM4558M-1 J AC Motor Driver,NJM4558M
IC801 VHI74HC153F-1 J AH Inverter,74HC153F
IC802 VHI74HCT04F-1 J AE Buffer Amp.,74HCT04F
IC803 VHITC74HCU04F J AF Amp.,TC74HCU04F
IC804 VHIYM3436D/-1 J BA Digital Interface Receiver,
YM3436D
IC805 VHITC7W04F/-1 J AD Inverter,TC7W04F
IC806 VHISM5844AF-1 J BF Sampling Rate Converter,
SM5844AF
IC807 VHITDA1307/-1 J BS 1Bit Conversion,TDA1307
IC808 VHI74ACT00F-1 J AE Control,74ACT00F
IC809 VHI74ACT00F-1 J AE Selector,74ACT00F
IC810 VHI74ACT00F-1 J AE Clock Selector,74ACT00F
IC812,813 VHI74LCX74F-1 J AF Waveform Rectification,
74LCX74F
IC814 VHINJM431U/-1 J AE Regulator,NJM431U
IC820 VHITC7WU04F-1 J AD PC Controll,TC7WU04F
IC821,822 VHITC7W04F/-1 J AD Inverter,TC7WU04F
IC901~903 VHIBU2114F+-1 J AL LED Driver,BU2114F
IC904 RH-IX2816AFZZ J AZ System Microcomputer,
IX2816AF
IC905 VHIPST9119+-1 J AE Reset,PST9119
ICA1 RH-IX2815AFZZ J AV 7th Order Modulation
Conversion LSI,IX2815AF
ICA2 VHI74AC00F/-1 J AE NAND Gate,74AC00F
ICA3 VHITAC08F//-1 J AE AND Gate,TAC08F
ICA4~7 VHIHIP2100/-1 J AQ FET Driver,HIP2100
TRANSISTORS
Q102 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q104 VS2SC1740SR-1 J AB Silicon,NPN,2SC1740 SR
Q105,106 VS2SC3242-F-1 J AC Silicon,NPN,2SC3242 F
Q108 VS2SC1740SR-1 J AB Silicon,NPN,2SC1740 SR
Q110 VS2SC1740SR-1 J AB Silicon,NPN,2SC1740 SR
Q112,113 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q114,115 VS2SD2394F/-1 J AE Silicon,NPN,2SD2394 F
Q116 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q118,119 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q201 VS2SA1037KR-1 J AB Silicon,PNP,2SA1037 KR
Q202 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q208 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q251 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q252 VS2SA1037KR-1 J AB Silicon,PNP,2SA1037 KR
Q602 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q604 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q605~608 VS2SA1036KR-1 J AC Silicon,PNP,2SA1036 KR
Q609~612 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q613,614 VS2SK389BL+-1 J AH FET,2SK389 BL
Q617,618 VS2SJ109BL+-1 J AM FET,2SJ109 BL
Q621,622 VS2SK170-BL-1 J AD FET,2SK170-BL
Q623,624 VS2SJ74BL++-1 J AG FET,2SJ74 BL
Q651~654 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q801~803 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
QA1~8 VS2SA1483//-1 J AM Silicon,PNP,2SA1483
QA9~16 VHIIRF530//-1 J AK FET,IRF530
DIODES
D101,102 VHD1SS133//-1 J AA Silicon,1SS133
D104,105 VHD1SS133//-1 J AA Silicon,1SS133
D107~109 VHDDA119///-1 J AA Silicon,DA119
D110~113 VHD11ES1///-1 J AB Silicon,11ES1
D201~209 VHDDA119///-1 J AA Silicon,DA119
D501,502 VHD1SS133//-1 J AA Silicon,1SS133
D503,504 VHDRK36++++-1 J AE FET,DRK36
D505 VHD1SS133//-1 J AA Silicon,1SS133
D601,602 VHDDA119///-1 J AA Silicon,DA119
D651,652 VHDDA119///-1 J AA Silicon,DA119
D801 VHD1SS133//-1 J AA Silicon,1SS133
D803,804 VHD1SS133//-1 J AA Silicon,1SS133
D901 VHD1SS133//-1 J AA Silicon,1SS133
DA1~8 VHD1SS355//-1 J AB Silicon,1SS355
DA9~16 VHDSM1XP2//-1 J AD Silicon,SM1XP2
DA17 VHDDA119///-1 J AA Silicon,DA119
LED901~903 VHPGL9BC030-1 J BA LED,White,GL9BC030
LED904~910 VHPLNG91LCF-1 J AN LED,White,LNG91LCF
ZD101 VHEMTZJ220C-1 J AB Zener,22V,MTZJ22C
ZD102,103 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
ZD104 VHEHZ5BLL//-1 J AC Zener,5V,HZ5BLL
ZD801,802 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
ZDA1~8 VHEHZU12B3+-1 J AB Zener,12V,HZU12B3
ZDA81~84 RH-EX0155CEZZ J AB Zener,6.9V,HZ7A3
FILTERS
FIL501~504 RFILN0010AFZZ J AR 1.5 µF,50V,Chip 3 Terminal
Capacitor
COILS
L101~108 RCILC0371AFZZ J AC Line Filter
L111~120 RCILC0371AFZZ J AC Line Filter
L201~203 VP-CH221K0000 J AB 220 µH,Noise Filter
! L501 RCILZ0317AFZZ J AR Line Filter
! L502,503 RCILZ0318AFZZ J AF Line Filter
L504~511 RCILZ0319AFZZ J AD 120 ohms at 100MHz
L801 VP-DH470K0000 J AB 47 µH,Choke
L802~804 VP-DH100K0000 J AB 10 µH,Choke
L805,806 RFILN2023SCZA J Line Filter,Digital Signal
L807~819 RCILC0371AFZZ J AC Line Filter,DC Power
L830,831 RCILC0371AFZZ J AC Line Filter,DC Power
L833 VP-DH470K0000 J AB 47 µH,Choke
L834A RCILC0371AFZZ J AC Line Filter
L834B VP-DH470K0000 J AB 47 µH,Choke
L835 VP-DH470K0000 J AB 47 µH,Choke
L901 VP-DH220K0000 J AB 22 µH,Choke
LA801 RCILZ0326AFZZ J AU 10.8 µH
LA802,803 RCILZ0327AFZZ J AU 10.8 µH
LA804 RCILZ0326AFZZ J AU 10.8 µH
LA805,806 RCILZ0323AFZZ J AV 5.6 µH
LA807,808 RCILZ0325AFZZ J AR 75 µH
VARIABLE RESISTORS
VOL601 RVR-A0265AFZZ J 20 kohms 20%,Semi-VR,
A Curve [Main Volume]
VOL602 RVR-A0266AFZZ J BD Semi-VR,Display Signal Detect
VRA1,2 RVR-M1583AFZZ J AE 200 ohms (B),Semi-VR
[Feedback Level Adjustment]
VRA3,4 RVR-M1611AFZZ J AE 1 kohm (B),Semi-VR
[Feedback Level Adjustment]
VIBRATORS
CXA1 RCRSB0354AFZZ J AS Crystal,11.2896 MHz
X801 RCRSB0353AFZZ J AK Crystal,11.2896 MHz
X901 RCRM-0202AFZZ J AD Ceramic,8.00 MHz
THERMISTOR
! R187,188 RH-QX1070AFZZ J AH Posistor,4.7 ohms
! R189,190 RH-QX1069AFZZ J AG Posistor,6.2 ohms
! R250 RH-QX1071AFZZ J AE Posistor,15 ohms
CAPACITORS
C101,102 VCKYTV1HB101K J AA 100 pF,50V
C105,106 VCKYTV1HB101K J AA 100 pF,50V
C107~110 RC-EZ1701AFZZ J AF 10 µF,25V,Electrolytic
C111,112 VCKYTV1HB101K J AA 100 pF,50V
C118,119 RC-EZ1701AFZZ J AF 10 µF,25V,Electrolytic
C120,121 VCEA4U1AN107M J AC 100 µF,10V,Electrolytic
C124 RC-EZ1689AFZZ J AD 100 µF,50V,Electrolytic
C125,126 RC-EZ1699AFZZ J AK 47 µF,20V,Electrolytic
C130 RC-EZ1689AFZZ J AD 100 µF,50V,Electrolytic
C131 VCKYTQ1CF105Z J AC 1 µF,16V
