NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
SM-SX100
CNW502 QCNWN6893AFZZ J Connector Ass’y,3Pin [110-127V]
CNW504A,B QCNWN6774AFZZ J AS Connector Ass’y,2Pin
CNW810 QCNWN6879AFZZ J Lug Wire
CNWAM1A/B/C QCNWN6790AFZZ J AS Connector Ass’y,4/2/2Pin
CNWAM2A/B/C QCNWN6789AFZZ J AS Connector Ass’y,6/3/3Pin
CNWAM3A/B QCNWN6777AFZZ J AX Connector Ass’y,9/9Pin
CNWAM4A/B QCNWN6776AFZZ J AR Connector Ass’y,3/3Pin
! COR501 RCORF0119AFZZ J AL Core
! F501 QFS-B702EAFNI J Fuse,7A/125V [110-127V]
! F501 QFS-C402KAFNI J AM Fuse,T4A L 250V [220-240V]
! F502,503 QFS-F322BAFNY J AE Fuse,T3.15A L 250V [220-240V]
! F502,503 QFS-L302AAFNZ J Fuse,3A/250V [110-127V]
J101,102 QJAKE0211AFZZ J BC Terminal,SACD
J103,104 QJAKE0211AFZZ J BC Terminal,LINE 1
J106 QJAKE0212AFZZ J BG Terminal,Canon Balance
J107,108 QJAKE0211AFZZ J BC Terminal,LINE OUT
J801 QJAKE0211AFZZ J BC Terminal,DIGITAL 3
J802 QSOCZ9166AFZZ J AX Terminal,DIGITAL 2
RLY101,102 RRLYZ0180AFZZ J AN Relay
RLY104,105 RRLYZ0180AFZZ J AN Relay
RLY106 RRLYD0119AFZZ J AN Relay
RLY107,108 RRLYD0118AFZZ J AM Relay
RLY201 RRLYZ0180AFZZ J AN Relay
RLY501 RRLYD0121AFZZ J AN Relay
RLY601,602 RRLYZ0180AFZZ J AN Relay
RLY801,802 RRLYZ0180AFZZ J AN Relay
RLYA1 RRLYD0120AFZZ J BB Relay
RX801 VHPTORX102/-1 J BL Optical Fiber Data Link,1,
TORX102
RX802 VHPGP1F32R/-1 J AP Optical Fiber Data Link,4,
GP1F32R
! SOC501 QSOCA2214AFZZ J AH AC Inlet
SOC801 QSOCD1302AFZZ J AK Terminal,1Bit
SW101 QSW-S0954AFZZ J AH Switch,Slide Type
[IMPEDANCE SELECTOR]
! SW501 QSW-P9235AFZZ J AH Switch,Push Type [POWER]
SW901 QSW-K0235AFZZ J AD Switch,Key Type [DIGITAL 1]
SW902 QSW-K0235AFZZ J AD Switch,Key Type [DIGITAL 2]
SW903 QSW-K0235AFZZ J AD Switch,Key Type [DIGITAL 3]
SW904 QSW-K0235AFZZ J AD Switch,Key Type [DIGITAL 4]
SW905 QSW-K0235AFZZ J AD Switch,Key Type [SACD]
SW906 QSW-K0235AFZZ J AD Switch,Key Type [LINE 1]
SW907 QSW-K0235AFZZ J AD Switch,Key Type [LINE 2]
TA101,102 QTANA9012AFZZ J BV Terminal,Speaker
TX801 VHPGP1F32T/-1 J AP Optical Fiber Data Link,
GP1F32T
UNT101 RUNTZ0739AFZZ J BM DC/DC Converter
! UNT501,502 RUNTZ0735AFZZ J DC/DC Converter
! UNT503 RUNTZ0749AFZZ J AC/DC Converter
CABINET PARTS
201 GCOVA3130AFSA J Side Panel,Left [Green]
201 GCOVA3130AFSB J Side Panel,Left [Blue]
201 GCOVA3130AFSD J Side Panel,Left [Black]
202 GCOVA3131AFSA J Side Panel,Right [Green]
202 GCOVA3131AFSB J Side Panel,Right [Blue]
202 GCOVA3131AFSD J Side Panel,Right [Black]
203 GCOVA3132AFSA J BM Side Panel,Left,Sub
204 GCOVA3133AFSA J BM Side Panel,Right,Sub
205 GCOVA3134AFSA J BF Net,Top Panel Heat
206 GITAR0317AFSA J BR Panel,Terminal
207 GITAT0069AFSA J Top Panel,A
208 GITAT0070AFSA J BV Top Panel,B
209 GITAU0052AFSA J Bottom Panel
210 GITAU0053AFSA J BA Bottom Panel,Sub
211 GLEGM0102AFSA J AZ Leg,Rear
212 HDECZ0187AFSA J AX Decoration,Selector Knob
213 HPNLC3699AFSA J Front Panel
214 HPNLH1537AFSA J BS Panel,Display
215 JKNBB0105AFSA J BM Knob,Volume
216 JKNBM1196AFSA J BK Knob,Power
217 JKNBZ2209AFSA J AE Knob,Selector
218 LANGF1626AFFW J AU Bracket,Power Heat Sink
219 LANGJ0165AFFQ J AV Bracket,Speaker Terminal
220 LANGK0962AFF1 J BL Bracket,Front Panel
221 LANGK0964AFF1 J BF Bracket,Main Volume
222 LANGK0967AFFW J AX Bracket,Amp Coil
223 LANGK0968AFFW J AX Bracket,FET PWB
224 LANGK0969AFFW J AX Bracket,FET Block
225 LANGK0970AFFW J AY Bracket,ST Terminal
226 LANGK0977AFF1 J AX Bracket,1Bit Terminal
227 LANGQ1217AFFQ J AV Bracket,Erase A
228 LANGQ1218AFFQ J AW Bracket,Erase B
229 LANGT1968AFFW J AT Bracket,Power Switch
230 LANGT1971AFF1 J BD Bracket,Connect A
231 LANGT1972AFF1 J BE Bracket,Connect B
232 LANGZ0366AFFW J AQ Bracket,Volume Protection
233 LBNDJ2003SCZZ J AA Nylon Band,100mm
234 LBSHZ0110AFZZ J AC Edge Saddle
235 LCHSM0947AFF1 J BU Main Chassis
236 LHLDW1009ACZZ J AB Clamper,Line Process
237 LHLDW1156AFZZ J AA Nylon Band,142mm
238 LHLDW1169AFZZ J AB Nylon Band,Holder Type
239 LHLDZ1776AF00 J AC Holder,LED
240 LHLDZ9218AFZZ J AD Holder,PWB
241 MJNT-3061AFZZ J BD Volume Joint Coupling
242 NSFTT1018AFZZ J AM Shaft,Volume Connect
243 PCUSS0773AF00 J AF Cushion,Power Switch
244 PCUSS0775AF00 J AF Cushion,Bottom Panel
245 PCUSS0778AF00 J AF Cushion
246 PFLT-1155AF00 J AF Felt
247 PRDAR0775AF00 J AW Heat Sink,Power
248 PRDAR0777AF00 J BA Heat Sink,1Bit Amp.
249 PRDAR0780AFZZ J AZ Brock,FET Heat
250 PRDAR0784AFFW J BA Heat Sink
251 PSHEG0200AFZZ J AN Sheet,Power Switch Heat
252 PSHEP0392AF0T J AF Sheet,Selector Keep
253 PSHEP0398AFSA J AG Sheet,Selector Diffusion
254 PSHEP0401AFZZ J AK Sheet,Insulator A
255 PSHEP0402AFZZ J AL Sheet,Insulator B
256 PSHEP0403AFZZ J AY Sheet,Insulator C
257 PSHEP0405AFZZ J AG Sheet,Insulator D
258 PSHEP0406AFZZ J AH Sheet,Insulator E
259 PSHEP0407AFZZ J AM Sheet,Insulator F
260 PSHEZ1121AFZZ J AR Sheet,FET Heat
261 PSHEZ1122AFZZ J AK Sheet,1Bit Amp Heat
262 PSHEZ1133AF0T J AE Sheet,Preventive Vibration A
263 PSHEZ1134AF0T J AG Sheet,Preventive Vibration B
264 PSLDM3755AFFN J BR Shield,1Bit Amp,Top
265 PSLDM3757AFZZ J BR Shield,1Bit Amp,
266 PSLDM3758AFZZ J BS Shield,1Bit Amp,Bottom
267 PSLDM3759AFF1 J BS Bottom Panel,Power Shield
268 PSLDM3760AFFN J BQ Shield,Power A
269 PSLDM3761AFFN J BM Shield,Power B
270 PSLDM3762AFFN J BM Shield,Power C
271 PSLDM3763AFFN J AX Shield,Power D
272 PSLDM3769AFF1 J BE Shield,Panel,AC Power
274 PSPAB0205AFFN J AE Hexagon Boss,h9mm
275 PSPAB0206AFFN J AE Hexagon Boss,h6mm
276 PSPAB0208AFFN J AE Hexagon Spacer,h20mm
277 PSPAB0212AFFN J AD Hexagon Spacer,h8mm
278 PSPAB0213AFFN J AD Hexagon Spacer,h14mm
279 PSPAB0215AFFN J AE Hexagon Spacer,h5mm
280 PSPAB0216AFFN J AE Hexagon Spacer,h16mm
281 PSPAB0217AFFW J AD PWB Spacer A
282 PSPAB0218AFFW J AD PWB Spacer B
283 PSPAB0219AFFN J AD Hexagon Boss,h10mm
284 PSPAB0222AFFN J AF Hexagon Spacer,h28mm
285 PSPAS0272AFZZ J AD Spacer,Power Knob
286 PSPAS0273AFZZ J AD Spacer,Selector
287 PSPAZ0578AFZZ J AD Stopper,Volume Knob
288 PSPAZ0579AFZZ J AD Spacer,FET
289 PSPAZ0585AFZZ J AD Spacer,1Bit Amp.
290 PSPAZ0589AFZZ J AD PWB Spacer,h3.5mm
291 PSPAZ0590AFZZ J AC PWB Spacer,h5mm
292 PSPAZ0591AFZZ J AC PWB Spacer,h10mm
293 PSPAZ0595AFZZ J AC PWB Spacer,h14mm
! 294 QFSHD2051AFZZ J AA Holder,Fuse
295 DSPC-3143AFA0 J Label,Specifications
[Except for Europe/Switzerland/
U.K./Singapore/Hong Kong/
U.S.A./Canada]
295 DSPC-3143AFE0 J Label,Specifications
[For U.K./Singapore]
295 DSPC-3143AFH0 J Label,Specifications
[For Europe/Switzerland]
295 DSPC-3143AFW0 J Label,Specifications
[For Hong Kong]
295 DSPC-3147AFU0 J Label,Specification
[For U.S.A./Canada]
296 PCUSG0702AFZZ J AG Cushion,Amp.
297 PCUSG0701AFZZ J AF Cushion,Top Panel
298 PSHEF0273AFZZ J AF Sheet,Spacer A
– 4 –
