4E
24" CONVECTION MICROWAVE DRAWER FLUSH MOUNT AND MEASUREMENTS
K
E
C
B
A
G
I
F
J
H
D
Prepare cabinet opening as shown in Figures 5, 6, 7
C
L
Top view
A
Mounting cleat
B
C
Drawer face
Cabinet
face
Note: the mounting surface of the finished cleat must
17
/32" (38.89 mm) back from the face of the cabinet.
Figure 5
Figure 6
A. Suggested electrical outlet location
B. 5" (127 mm)
C. 4" (101.60 mm)
D. 23
7
/8" (606.43 mm)
E. 19
3
/8" (492.12 mm)
F. 1
5
/8" (41.27 mm)
G. 23
1
/2" (596.90 mm) minimum depth
H. 23
5
/8" (600.07 mm)
I. 1
5
/8" (41.27 mm) to front of shelf
J. 19
3
/4" (501.65mm) opening
K. Floor must support 100 lb (45.4 kg)
A. 22
3
/8" (568.32 mm) mounting cleat opening width
B. 0" ush
C. 1
5
/8" (41.27 mm) front of cleat to cabinet face
C
No oven shown
B
A
Suggested electrical
outlet location
Figure 7
A. 22
3
/8" (568.32 mm) mounting cleat opening width
B. 23
7
/8" (606.43 mm) ush opening width
C.
1
/8" (3.17 mm) from opening to top of shelf
