Sharp SMD3070ASY Service Manual

34
SMD2470ASY SMD3070ASY
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-22 PCUSGA851WRPZ FAN MOTOR SUPPORT CUSHION 1 AC
4-23 PCUSGA810WRPZ AIR FLOW CUSHION 1 AT
4-24 PCUSUA687WRPZ CUSHION 1 AD
4-25 PDMP-B003MRE0 OIL DAMPER 1 AC
4-26 PDUC-B141MRP0A MAG DUCT 1 AE
4-27 PDUC-B191WRFZ SENSOR DUCT 1 AR
4-28 PDUC-B192WRFZ EXHAUST DUCT 1 AR
4-29 PFILWA066WRPZ LAMP FILTER 1 AB
4-30 PSKR-A516WRPZ PARTITION AG BOTTOM 1 AM
4-31 PSKR-A517WRWZ PARTRITION AG REAR 1 AM
4-32 PHOK-A178WRFZ LATCH HOOK R 1 AG
4-33 PHOK-A174WRFZ LATCH HOOK L 1 AG
4-34 PCOVPA667WRPZ FACEPLATE OUTERCASE COVER 1 AR
DOOR PARTS
5-1 FCOV-B533MRK0A DOOR FRAME ASSY (SMD2470ASY) 1 BR
5-1 FCOV-B541MRK0 DOOR FRAME ASSY (SMD3070ASY) 1 BR
5-2 FDORFA531WRYZ DOOR PANEL ASSY 1 BK
5-3 LSTPPB072MRF0 LATCH HEAD R 1 AD
5-4 LSTPPB073MRF0 LATCH HEAD L 1 AD
5-5 MSPRTB035MRE0 LATCH SPRING 2 AD
5-6 PSHEPB255MRE0 SEALER FILM 1 AM
5-7 LX-HZB001MRE0 SPECIAL SCREW 2 AA
5-8 XCPS740P08000 M4 X 8 SCREW - TAP PAN HEAD 11 AA
5-9 GCOVHB067MRF0 CHOKE COVER (SMD2470ASY) 1 AY
5-9 GCOVHB076MRF0 CHOKE COVER (SMD3070ASY) 1 AM
MISCELLANEOUS
6-1 TINSEB538MRR0 OP MANUAL ASSY 1 AE
6-2 TINSEB539MRR0 INSTALLATION INSTRUCTIONS 1 AA
6-3 LX-CZB055MRE0 WOOD SCREW (M4 X 20, PANHEAD) 4 AA
6-4 TCAUAA387WRRZ DHHS/GRD/CAUTION LABEL 1 AD
6-5 TCAUAB050MRR0 MONITOR CAUTION LABEL 2 AD
6-6 TCAUAB059MRR0 CONSUMER WARNING LABEL 1 AA
6-7 TCAUHA412WRRZ USER CAUTION LABEL 1 AA
6-8 TCAUAA392WRRZ WAVEGUIDE COVER CLEANING LABEL 1 AA
6-9 TLAB-B105MRR0 MENU LABEL 1 AB
6-10 TMAPCA825WRRZ SCHEMATIC DIAGRAM 1 AC
SCREWS, NUTS, AND WASHERS
7-1 LX-BZA041WRE0 M4-POINTED-8 11 AA
7-2 LX-CZ0052WRE0 SCREW WITH WASHER 2 AA
7-3 LX-CZA084WREZ SCREW 3 AA
7-4 LX-CZA107WREZ SCREW WITH WASHER 2 AA
7-5 LX-NZB006MRE0 CAP NUT 2 AA
7-6 LX-NZB012MRE0 CAP NUT 4 AA
7-7 XCBS730P08000 M3 X 8 SCREW - TAP BINDING HEA 4 AB
7-8 XOTS740P12RV0 M4 X 12 SCREW - COMMON (RoHS) 8 AB
7-9 XEPS730P10XS0 M3 X 10 SCREW - STEEL P-TIGHT 7 AC
7-10 XHPS740P08K00 SCREW: 4MM X 8MM 5 AB
7-11 XHTS740P06000 4x6mm SCREW 2 AC
7-12 XHTS740P08000 M4 X 8 SCREW - T TAP TRUSS (Ro 5 AD
7-13 XOTS740P12000 CABINET SCREW/ CLEAR (RoHS) 58 AB
