Sharp SMD3070ASY Service Manual

6
SMD2470ASY SMD3070ASY
ITEM DESCRIPTION
Power Requirements 120 Volts
14.5 Amperes, 1000 watts
60 Hz
Single phase, 3 wire grounded
Standby power: 1 Watt
Power Output 1000 watts (IEC TEST PROCEDURE)
Operating frequency of 2450MHz
Cooking Cavity Dimensions Width 17-11/32
Height 7-7/8"
1.2 Cubic Feet Depth 16-1/2"
SMD2470AS SMD3070AS
Outside Dimensions Width 23-7/8" 30"
Height 15-3/4" 15-3/4"
Depth 23-1/16" 23-1/16"
SMD2470AS SMD3070AS
Packing Case Dimensions Width 27-11/16" 33-5/8"
Height 21-1/2" 21-1/2"
Depth 29-1/16" 29-1/16"
(Packed unit) 86 Lbs 91lbs
Control Complement Touch Control System
Clock ( 1:00 - 12:59 )
Timer (0 - 99 min. 99 seconds)
Microwave Power for Variable Cooking
Repetition Rate;
P-HI .................................................. Full power throughout the cooking time
P-90 ..................................................................... approx. 90% of Full Power
P-80 ..................................................................... approx. 80% of Full Power
P-70 ..................................................................... approx. 70% of Full Power
P-60 ..................................................................... approx. 60% of Full Power
P-50 ..................................................................... approx. 50% of Full Power
P-40 ..................................................................... approx. 40% of Full Power
P-30 .................................................................... approx. 30% of Full Power
P-20 ..................................................................... approx. 20% of Full Power
P-10 ..................................................................... approx. 10% of Full Power
P-0 ..................................................... No power throughout the cooking time
SENSOR: Popcorn, Reheat, Potatoes, Vegetables, Cook
SETTINGS: Beverage, Defrost, Melt/Soften, Keep Warm, Help/Settings,
Open/Close, Start/+30 sec, Stop/Clear, Power Level, Timer/Clock,
Number Pad
Oven Cavity Light Yes
Safety Standard UL Listed FCC Authorized
MICROWAVE DRAWER SPECIFICATION
