Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
169
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
R5782 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R5787 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R5788 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R5789 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R5790 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R5791 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB1105 RBLN-0049TAZZY J Ferrite Bead AA
FB3802 RBLN-0061TAZZY J Ferrite Bead AD
FB3803 RBLN-0049TAZZY J Ferrite Bead AA
FB5701 RBLN-0049TAZZY J Ferrite Bead AA
FB5702 RBLN-0049TAZZY J Ferrite Bead AA
FB5706 RBLN-0049TAZZY J Ferrite Bead AA
LUG1103 QLUGHA006WJZZY J Lug AC
LUG1104 QLUGHA006WJZZY J Lug AC
LUG1105 QLUGHA006WJZZY J Lug AC
LUG1106 QLUGHA006WJZZY J Lug AC
J1103 QTANJA040WJZZ J Terminal AL
J1104 QTANJA044WJZZ J Terminal AD
J1105 QTANJA046WJZZ J Terminal AH
P1105 QPLGNA102WJZZY J Plug, 13Pin(DA) AE
P3800 QPLGN0567FJZZY J Plug, 5Pin(SF) AD
P3801 QPLGNA238WJZZY J Plug, 15Pin(SA) AE
P3802 QPLGN0572FJZZY J Plug, 10Pin(MA) AE
P3803 QPLGNA349WJZZY J Plug, 15Pin(MB) AE
P3804 QPLGNA170WJZZ J Plug, 30Pin(AF) AD
P3805 QPLGN0566FJZZY J Plug, 4Pin(AD) AD
P3806 QPLGN0578GEZZ J Plug, 5Pin AB
P5701 QCNCWA202WJZZY J Connector, 60Pin AK
P5702 QCNCWA202WJZZY J Connector, 60Pin AK
P5703 QPLGNA168WJZZY J Plug, 12Pin(PA) AF
P5705 QPLGN0570FJZZY J Plug, 8Pin(PS) AD
P5708 QPLGNA046WJZZ J Plug, 7Pin(SJ) AC
P5710 QPLGN0569FJZZY J Plug, 7Pin(DS) AE
P5711 QPLGN0564FJZZY J Plug, 2Pin(AH) AD
RY3800 RRLYDA004WJZZ J Relay AN
SC1101 QSOCD0456CEZZ J Socket AE
SC3802 QSOCN0493FJZZY J Socket, 45Pin(FC) AG
QCNW-C026WJQZ J Connecting Cord AH
QCNW-C030WJPZ J Connecting Cord AF
DUNTKC736FE01/FE02/FE03
AV UNIT(Continued)
INTEGRATED CIRCUITS
IC701 95KUCB0247AZ J I C, MIP2D2 0MPSCF AH
IC702 95KUCY0136AZ J I C (CHIP), FA5501N-TE1 AL
IC703 95KUCY0159AY J I C (SOP), L6565DTR AH
IC901 95KUCB0166AK J I C, UPC1093J-1-T AD
IC902 95KUCY0166AY J I C (SOP),
S-1170B50UC-OUJ-TF AH
IC903 95KUCB0166AK J I C, UPC1093J-1-T AD
IC904 95KUCY0160AY J I C (SOP), STSR30D-TR AN
IC905 95KUCY0161AY J I C (SOP), LM2642MTCX AT
IC906 95KUCY0138AZ J I C (SOP), BA10393F-E2 AD
TRANSISTORS
Q701 95KUAC0027CK J 2SC2655-Y(TPE6 C) AD
Q702 95KUAY0120BK J 2SC4097-T106 QR AC
Q705 95KUAG0214BZ J 2SK3326 (6) AK
Q706 95KUAG0239AK J 2SK3532-01MR F119SC AM
Q707 95KUAY0146AZ J IMZ1A T108 AC
Q708 95KUAY0146AZ J IMZ1A T108 AC
Q711 95KUAC0027CK J 2SC2655-Y(TPE6 C) AD
Q712 95KUAC0230AB J 2SC3632-K AF
Q901 95KUAY0120BK J 2SC4097-T106 QR AC
Q902 95KUAG0249AZ J 2SK3715 AP
Q903 95KUAC0027CK J 2SC2655-Y(TPE6 C) AD
Q904 95KUAF0081AK J DTC114EKA T146 AC
Q907 95KUAY0158AZ J SI4894DY AF
Q908 95KUAY0158AZ J SI4894DY AF
DIODES
D701 95KUBY0078AK J 1SS400 TE-61 AB
D704 95KUBB0259AK J D1UBA80-4062 AD
D705 95KUBC0169DK J ERA22-08V1 AD
D706 95KUBY0072AK J 1SS376TE-17 AC
D707 95KUBY0008AK J D1FL20U-4063 AC
D708 95KUBB0149DZ J D3SBA60 AH
D709 95KUBH0002GZ J SF5L60-4100 AG
D710 95KUBY0008AK J D1FL20U-4063 AC
D711 95KUBY0078AK J 1SS400 TE-61 AB
D713 95KUBY0008AK J D1FL20U-4063 AC
D715 95KUBC0169EK J ERA22-10V1 AD
D716 95KUBY0008AK J D1FL20U-4063 AC
D717 95KUBY0008AK J D1FL20U-4063 AC
D718 95KUBY0078AK J 1SS400 TE-61 AB
D719 95KUBY0078AK J 1SS400 TE-61 AB
D720 95KUBY0078AK J 1SS400 TE-61 AB
D721 95KUBY0078AK J 1SS400 TE-61 AB
D722 95KUBY0078AK J 1SS400 TE-61 AB
D723 95KUBY0078AK J 1SS400 TE-61 AB
D901 95KUBC0207BK J ERB83-006V1 AD
D902 95KUBC0425AY J D1F60-4063 AC
D903 95KUBC0087AK J ERC81-006V11 AD
D905 95KUBY0078AK J 1SS400 TE-61 AB
D906 95KUBY0078AK J 1SS400 TE-61 AB
D907 95KUBY0078AK J 1SS400 TE-61 AB
D908 95KUBY0078AK J 1SS400 TE-61 AB
D909 95KUBY0078AK J 1SS400 TE-61 AB
D910 95KUBY0078AK J 1SS400 TE-61 AB
D911 95KUBY0078AK J 1SS400 TE-61 AB
D912 95KUBY0078AK J 1SS400 TE-61 AB
D914 95KUBY0090AK J RB520S-30 AC
D915 95KUBY0068AZ J D1FM3-4063 AD
D916 95KUBY0078AK J 1SS400 TE-61 AB
ZD701 95KUBDCH270C J Zener Diode, MTZJ T-77 27B AB
ZD702 95KUBDCQ201B J Zener Diode, 1ZB200-Y (TPA2) AB
ZD703 95KUBXBM270B J Zener Diode, UDZS TE-17 27B AB
ZD704 95KUBDCH270C J Zener Diode, MTZJ T-77 27B AB
ZD705 95KUBDCH5R6C J Zener Diode, MTZJ T-77 5.6B AB
ZD706 95KUBDRB2R0A J Zener Diode, RD2.0FB2-T7 AB
ZD707 95KUBXBM5R6B J Zener Diode, UDZS TE-17 5.6B AB
ZD708 95KUBDCH160C J Zener Diode, MTZJ T-77 16B AB
RDENCA064WJZZ
RDENCA110WJZZ
POWER SUPPLY UNIT
