Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
170
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
C732 95KUGCV102JY J 1000p 2kV AC
C733 95KUGCV101JZ J 100p 1kV AC
C734 95KUGXGFD104 J 0.1 25V AB
C735 95KUGXGCF103 J 0.01 50V AB
C736 95KUGDE330CZ J 33 35V Electrolytic AC
C737 95KUGCM102GL J 1000p 50V AC
C739 95KUGXGDF220 J 22p 50V AB
C740 95KUGCM102GL J 1000p 50V AC
C742 95KUGXJSF102 J 1000p 50V AB
C743 95KUGXGFD104 J 0.1 50V AB
C744 95KUGXGFD104 J 0.1 25V AB
C745 95KUGXMTD224 J 0.22 25V AB
C746 95KUGXGDF220 J 22p 50V AB
C748 95KUGXKEF224 J 0.22 50V AC
C749 95KUGXGDF101 J 100p 50V AB
C901 95KUGDB471FK J 470 10V Electrolytic AC
C902 95KUGDB101AP J 100 10V Electrolytic AC
C903 95KUGXGFD104 J 0.1 25V AB
C904 95KUGXGDF471 J 470p 50V AB
C905 95KUGXGFD104 J 0.1 25V AB
C906 95KUGDF100CZ J 10 50V Electrolytic AC
C907 95KUGDD182FZ J 1800 25V Electrolytic AF
C908 95KUGDD182FZ J 1800 25V Electrolytic AF
C909 95KUGDD182FZ J 1800 25V Electrolytic AF
C910 95KUGDD821FM J 820 25V Electrolytic AE
C912 95KUGXGFD104 J 0.1 25V AB
C915 95KUGXGDF471 J 470p 50V AB
C917 95KUGXGFD104 J 0.1 25V AB
C918 95KUGXGFD104 J 0.1 25V AB
C919 95KUGXGDF220 J 22p 50V AB
C920 95KUGXGDF220 J 22p 50V AB
C921 95KUGXGDF220 J 22p 50V AB
C922 95KUGXMTD224 J 0.22 25V AB
C925 95KUGXMUZ220 J 22 20V AG
C926 95KUGXMUZ220 J 22 20V AG
C927 95KUGXGFD104 J 0.1 25V AB
C928 95KUGXGCF103 J 0.01 50V AB
C929 95KUGXGFD104 J 0.1 25V AB
C930 95KUGXMZC105 J 1 16V AB
C931 95KUGXHEA105 J 1 6.3V AC
C932 95KUGXNAC475 J 4.7 16V AC
C933 95KUGXGCF103 J 0.01 50V AB
C934 95KUGXMVC820 J 82 16V AH
C935 95KUGXMVC820 J 82 16V AH
C936 95KUGXGFD104 J 0.1 25V AB
C937 95KUGXGCF332 J 3300p 50V AB
C938 95KUGXMTD474 J 0.47 25V AB
C939 95KUGXMTD224 J 0.22 25V AB
C940 95KUGXGFD104 J 0.1 25V AB
C941 95KUGXGDF101 J 100p 50V AB
RESISTORS
R701 95KUEXDBA224 J 220k 1/4W AB
R702 95KUEXDBA224 J 220k 1/4W AB
R703 95KUEXDBA224 J 220k 1/4W AB
R704 95KUEZ0550ZZ J 6.8M 1/2W AD
(TU-GD10U-T/TU-45GAT)
R704 95KUEZ0850ZZ J 6.8M 1W Resistor AB
(TU-45GAD)
R705 95KUEXBAW473 J 47k 1/10W AB
R706 95KUEXCBR392 J 3.9k 1/8W AB
R707 95KUEXBAW472 J 4.7k 1/10W AB
R708 95KUEXBAX000 J 0 1/10W AB
R713 95KUEXBAW682 J 6.8k 1/10W AB
R716 95KUEFD104ES J 100k 1W AC
R718 95KUEXBAW474 J 470k 1/10W AB
R719 95KUEXBAW153 J 15k 1/10W AB
R720 95KUEXCBU000 J 0 1/10W AB
R721 95KUEXCBR2R2 J 2.2 1/8W AB
R726 95KUEXDBA824 J 820k 1/4W AB
R727 95KUEXDBA824 J 820k 1/4W AB
R728 95KUEXDBA824 J 820k 1/4W AB
R729 95KUEXBAW273 J 27k 1/10W AB
R732 95KUEXCBR473 J 47k 1/8W AB
R733 95KUEXCAS220 J 22 1/8W AB
R734 95KUEXCAS100 J 10 1/8W AB
ZD709 95KUBDCH270C J Zener Diode, MTZJ T-77 27B AB
ZD901 95KUBDCH5R6C J Zener Diode, MTZJ T-77 5.6B AB
ZD902 95KUBXBM5R6B J Zener Diode, UDZS TE-17 5.6B AB
ZD903 95KUBXBM180B J Zener Diode, UDZS TE-17 18B AB
ZD904 95KUBXBM160B J Zener Diode, UDZS TE-17 16B AB
ZD905 95KUBXBM130B J Zener Diode, UDZS TE-17 13B AB
PC701 95KUDY0014AK J Photo Coupler AD
PS2561L2-1-V-E3L
PC702 95KUDY0014AK J Photo Coupler AD
PS2561L2-1-V-E3L
PC703 95KUDY0014AK J Photo Coupler AD
PS2561L2-1-V-E3L
PC704 95KUDY0014AK J Photo Coupler AD
PS2561L2-1-V-E3L
SG701 95KUZZ0246ZZ J RA-302M-V7-Y AH
(TU-GD10U-T/TU-45GAT)
TH701 95KUEZ0501ZZ J Thermistor, M5R107CS AD
VZ701 95KUERALH471 J Varistor, ENC471D-10A AD
VZ702 95KUERALH471 J Varistor, ENC471D-10A AD
(TU-GD10U-T/TU-45GAT)
VZ703 95KUERALH471 J Varistor, ENC471D-10A AD
COILS AND TRANSFORMERS
L701 95KUKZ1271ZZ J Filter, SS11H-R08125 AE
L702 95KUKZ1271ZZ J Filter, SS11H-R08125 AE
L703 95KUKZ1249ZZ J Coil, TN1819T-02102 AH
L704 95K829195011 J Transformer, CHT117-KTC AH
L705 95KUKZ1283ZZ J Filter, SU9VF-02100 AE
L901 95KUKZ1208ZZ J Coil, PJ5H-220 AC
L902 95KUKZ1242ZZ J Coil, PC13-3R9N AE
L903 95KUKZ1243ZZ J Coil, H•DI-1280G-7R0 AK
L904 95KUKZ1038ZZ J Coil, PC8-3R3M AE
(TU-GD10U-T/TU-45GAT)
L904 95KUKZ0784ZZ J Coil, PC8T-3R3M AE
(TU-45GAD)
T701 95K829195010 J Transformer, PTTX93-KTC AG
T702 95K830195007 J Transformer, PTTX98-KTC AN
CAPACITORS
C701 95KUGFZ224MN J 0.22 275V AD
C702 95KUGFZ224MN J 0.22 275V AD
C703 95KUGFZ224MN J 0.22 275V AD
C704 95KUGCM332GL J 3300p 50V AD
C705 95KUGCM332GL J 3300p 50V AD
C706 95KUGCM332GL J 3300p 50V AD
C707 95KUGDQ6R8FL J 6.8 400V Electrolytic AE
C708 95KUGCU471JE J 470p 1kV AC
C709 95KUGDD221BJ J 220 25V Electrolytic AD
C710 95KUGDF2R2CZ J 2.2 50V AC
C711 95KUGXGFD104 J 0.1 25V AB
C712 95KUGCM102GL J 1000p 50V AC
C713 95KUGCM102GL J 1000p 50V AC
C714 95KUGXGCF221 J 220p 50V AB
C716 95KUGXMTD224 J 0.22 25V AB
C717 95KUGXGFD104 J 0.1 25V Ceramic(CHIP) AB
(TU-45GAD)
C718 95KUGXGFD104 J 0.1 25V Ceramic(CHIP) AB
(TU-45GAD)
C719 95KUGXGFD104 J 0.1 25V AB
C720 95KUGFR684QB J 0.68 450V AF
C722 95KUGCU331BS J 330p 1kV AC
C723 95KUGXGCF103 J 0.01 50V AB
C724 95KUGXGCF222 J 2200p 50V AB
C725 95KUGXAED334 J 0.33 25V AC
C726 95KUGXJSF102 J 1000p 50V AB
C728 95KUGXGFD333 J 0.33 25V AB
C729 95KUGDF220CZ J 22 50V Electrolytic AC
C730 95KUGXAEF104 J 0.1 50V AB
C731 95KUGDR820FX J 82 450V Electrolytic AM
RDENCA064WJZZ
RDENCA110WJZZ
POWER SUPPLY UNIT(Continued)
