Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
171
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
R735 95KUEFER68ER J 0.68 2W AC
R736 95KUEFER68ER J 0.68 2W AC
R737 95KUEXBAW101 J 100 1/10W AB
R738 95KUEXBAW561 J 560 1/10W AB
R739 95KUEYCR6803 J 680k 1/4W AB
R740 95KUEYCR6803 J 680k 1/4W AB
R741 95KUEYCR8203 J 820k 1/4W AB
R742 95KUEYCN1502 J 15k 1/10W AB
R743 95KUEXBAW103 J 10k 1/10W AB
R746 95KUEFD333ES J 33k 1W AC
R747 95KUEXCBR473 J 47k 1/8W AB
R748 95KUEFD333ES J 33k 1W AC
R749 95KUEFD333ES J 33k 1W AC
R750 95KUEFER68ER J 0.68 2W AC
R751 95KUEXCBR471 J 470 1/8W AB
R752 95KUEXCBR220 J 22 1/8W AB
R753 95KUEXCBR333 J 33k 1/8W AB
R758 95KUEXCBR165 J 1.6M 1/8W AB
R759 95KUEXCBR165 J 1.6M 1/8W AB
R760 95KUEXCBR165 J 1.6M 1/8W AB
R761 95KUEXCBR682 J 6.8k 1/8W AB
R766 95KUEXCBR472 J 4.7k 1/8W AB
R767 95KUEXBAX000 J 0 1/10W AB
R768 95KUEXBAW473 J 47k 1/10W AB
R773 95KUEXBAW331 J 330 1/10W AB
R774 95KUEXBAW331 J 330 1/10W AB
R775 95KUEXBAW103 J 10k 1/10W AB
R776 95KUEXBAW103 J 10k 1/10W AB
R777 95KUEXBAW102 J 1k 1/10W AB
R780 95KUEXBAW103 J 10k 1/10W AB
R781 95KUEXBAW562 J 5.6k 1/10W AB
R782 95KUEXBAW473 J 47k 1/10W AB
R783 95KUEXBAW563 J 56k 1/10W AB
R784 95KUEXBAW562 J 5.6k 1/10W AB
R785 95KUEXBAW562 J 5.6k 1/10W AB
R787 95KUEYCR2613 J 261k 1/4W AB
R788 95KUEXCBR472 J 4.7k 1/8W AB
R789 95KUEFE562FT J 5.6k 2W AC
R790 95KUEFE562FT J 5.6k 2W AC
R791 95KUEFE562FT J 5.6k 2W AC
R792 95KUEYCR2613 J 261k 1/4W AB
R793 95KUEYCR2613 J 261k 1/4W AB
R794 95KUEXCBR683 J 68k 1/8W AB
R795 95KUEXCBR563 J 56k 1/8W AB
R901 95KUEXBAW121 J 120 1/10W AB
R902 95KUEXBAW152 J 1.5k 1/10W AB
R903 95KUEXBAW101 J 100 1/10W AB
R904 95KUEYCN1002 J 10k 1/10W AB
R905 95KUEYCN1001 J 1k 1/10W AB
R906 95KUEYCN1002 J 10k 1/10W AB
R907 95KUEXBAW101 J 100 1/10W AB
R908 95KUEXBAW102 J 1k 1/10W AB
R909 95KUEXBAW222 J 2.2k 1/10W AB
R910 95KUEXBAW102 J 1k 1/10W AB
R911 95KUEYCN1002 J 10k 1/10W AB
R912 95KUEYCN1201 J 1.2k 1/10W AB
R913 95KUEYCN2201 J 2.2k 1/10W AB
R914 95KUEXBAW103 J 10k 1/10W AB
R915 95KUEXBAW561 J 560 1/10W AB
R916 95KUEXBAW102 J 1k 1/10W AB
R918 95KUEXCBR472 J 4.7k 1/8W AB
R919 95KUEXCBU000 J 0 1/10W AB
R920 95KUEXJAY472 J 4.7k 1/2W AB
R921 95KUEXBAH153 J 15k 1/10W AB
R922 95KUEXBAW222 J 2.2k 1/10W AB
R923 95KUEXBAW103 J 10k 1/10W AB
R924 95KUEXBAW103 J 10k 1/10W AB
R926 95KUEXBAH563 J 56k 1/10W AB
R927 95KUEXBAW222 J 2.2k 1/10W AB
R928 95KUEXBAW223 J 22k 1/10W AB
R929 95KUEXBAW682 J 6.8k 1/10W AB
R930 95KUEXBAW102 J 1k 1/10W AB
R931 95KUEXBAW122 J 1.2k 1/10W AB
R934 95KUEYCX15L0 J 15m 1/2W AB
R935 95KUEYCX15L0 J 15m 1/2W AB
R936 95KUEXBAW4R7 J 4.7 1/10W AB
R937 95KUEYCY9102 J 91k 1/10W AB
R938 95KUEYCY1202 J 12k 1/10W AB
R939 95KUEYCY1203 J 120k 1/10W AB
R940 95KUEXBAX000 J 0 1/10W AB
(TU-GD10U-T/TU-45GAT)
R940 95KUEXBAW150 J 15 Resistor(CHIP)AB
(TU-45GAD)
R941 95KUEXBAX000 J 0 1/10W AB
(TU-GD10U-T/TU-45GAT)
R941 95KUEXBAW150 J 15 Resistor(CHIP)AB
(TU-45GAD)
R942 95KUEXBAW682 J 6.8k 1/10W AB
R943 95KUEXBAW102 J 1k 1/10W AB
R944 95KUEXBAW4R7 J 4.7 1/10W AB
R945 95KUEXBAW222 J 2.2k 1/10W AB
R994 95KUEYCN8202 J 82k 1/10W AB
R995 95KUEXBAW205 J 2M 1/10W AB
R996 95KUEXBAX000 J 0 1/10W AB
R997 95KUEXBAW223 J 22k 1/10W AB
BALUNES
FB701 95KBFZ89856Z J Ferrite Bead AB
FBR07HA850SB-00
FB703 95KBFZ89856Z J Ferrite Bead AB
FBR07HA850SB-00
MISCELLANEOUS PARTS
F701 95KPJCZZ0197 J Fuse, ET 2A AE
F702 95KPJCZZ0088 J Fuse, FFT 1A AE
F703 95KPJT0185ZZ J Thermal Fuse, P110A AD
FH701 95KPZZ0625ZZ J Fuse Holder, PFC5000-0502 AB
FH702 95KPZZ0625ZZ J Fuse Holder, PFC5000-0502 AB
CD902 95KECB8161ZZ J Housing, MC306-7505B AL
CD903 95KECB8162ZZ J Housing, MC306-7506B AL
CD904 95KECB8163ZZ J Housing, MC306-7507B AL
CN701 95KPCZ0401ZZ J Inlet, CCT2302-0911 AE
(TU-GD10U-T/TU-45GAT)
CN701 95KPEZ0139ZZ J Inlet, CCT2302-0711 AE
(TU-45GAD)
CN901 95KPCZ0381ZZ J Connector, B08B-PASK-1(LF) AE
CN902 95KPCZ0382ZZ J Connector, B07B-PASK-1(LF) AE
CN903 95KPGZ0039ZZ J Jack, HEC8110-010010 AG
CN904 95KPCZ0391ZZ J Connector, B03B-PASK-1(LF) AD
LU901 95KPZZ0839ZZ J M1866 AB
LU902 95KPZZ0839ZZ J M1866 AB
LU903 95KFBZ0202ZZ J Lug, 0G-R30 AE
LU904 95KFBZ0202ZZ J Lug, 0G-R30 AE
LU905 95KFBZ0202ZZ J Lug, 0G-R30 AE
LU906 95KFBZ0202ZZ J Lug, 0G-R30 AE
LU907 95KFBZ0202ZZ J Lug, 0G-R30 AE
M901 95KLRZ7093ZR J Heat Sink, MC306-5001A AL
(TU-GD10U-T/TU-45GAT)
M901 95KLRZ7136ZR J Heat Sink, MC306-5001AC
(TU-45GAD)
M902 95KLRZ7094ZR J Heat Sink, MC306-5002A AH
(TU-GD10U-T/TU-45GAT)
M902 95KLRZ7137ZR J Heat Sink, MC306-5002AC
(TU-45GAD)
M903 95KLRZ7095ZQ J Angle, MC306-5003A AM
(TU-GD10U-T/TU-45GAT)
M903 95KLRZ7138ZQ J Angle, MC306-5003AC
(TU-45GAD)
MD902 95KGZZ5627ZZ J Insulation Sheet, MC306-3002A AF
(TU-45GAD)
NP901 95KSBB2901ZZ J Label, MC306-6001A AC
(TU-GD10U-T/TU-45GAT)
NP902 95KSBB2911ZZ J Label, MC306-6002A AC
RY701 95KPHZ0216ZZ J Relay, G5PA-1DC5V(PF) AH
RDENCA064WJZZ
RDENCA110WJZZ
POWER SUPPLY UNIT(Continued)
