Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
172
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
INTEGRATED CIRCUITS
IC951 95KUCY0169AY J IC (SOP), MD1422N-4072 AT
IC952 95KUCY0171AY J IC (SOP), MD1222N-4072
IC1701 95KUCC0147AY J IC, PQ1CX12H2ZP AM
IC1702 95KUCC0147AY J IC, PQ1CX12H2ZP AM
IC1703 95KUCC0147AY J IC, PQ1CX12H2ZP AM
IC1704 95KUCC0147AY J IC, PQ1CX12H2ZP AM
IC1705 95KUCY0170AY J IC (SOP), LT1910 ES8 AT
IC1708 95KUCY0177AY J IC, PQ20WZ1U AH
TRANSISTORS
Q950 95KUAY0120BK J 2SC4097-T106 QR AC
Q951 95KUAY0120BK J 2SC4097-T106 QR AC
Q952 95KUAG0236AZ J SI4431ADY AH
Q953 95KUAY0120BK J 2SC4097-T106 QR AC
Q1701 95KUAY0198AY J DTC144EE T146 AB
Q1702 95KUAY0120BK J 2SC4097-T106 QR AC
Q1703 95KUAY0198AY J DTC144EE T146 AB
Q1704 95KUAY0120BK J 2SC4097-T106 QR AC
Q1705 95KUAY0198AY J DTC144EE T146 AB
Q1706 95KUAY0120BK J 2SC4097-T106 QR AC
Q1707 95KUAY0198AY J DTC144EE T146 AB
Q1708 95KUAY0120BK J 2SC4097-T106 QR AC
Q1709 95KUAY0158AZ J SI4894DY AF
Q1715 95KUAY0120BK J 2SC4097-T106 QR AC
DIODES
D951 95KUBY0078AK J 1SS400 TE-61 AB
D952 95KUBY0068AZ J D1FM3-4063 AD
D953 95KUBY0078AK J 1SS400 TE-61 AB
D954 95KUBY0078AK J 1SS400 TE-61 AB
D955 95KUBY0068AZ J D1FM3-4063 AD
D956 95KUBY0078AK J 1SS400 TE-61 AB
D1701 95KUBY0077AZ J M1FH3-4063 AD
D1702 95KUBY0068AZ J D1FM3-4063 AD
D1703 95KUBY0078AK J 1SS400 TE-61 AB
D1705 95KUBY0077AZ J M1FH3-4063 AD
D1706 95KUBY0068AZ J D1FM3-4063 AD
D1707 95KUBY0078AK J 1SS400 TE-61 AB
D1709 95KUBY0077AZ J M1FH3-4063 AD
D1710 95KUBY0068AZ J D1FM3-4063 AD
D1711 95KUBY0078AK J 1SS400 TE-61 AB
D1712 95KUBY0077AZ J M1FH3-4063 AD
D1713 95KUBY0068AZ J D1FM3-4063 AD
D1714 95KUBY0078AK J 1SS400 TE-61 AB
D1715 95KUBY0078AK J 1SS400 TE-61 AB
D1716 95KUBY0078AK J 1SS400 TE-61 AB
D1717 95KUBY0068AZ J D1FM3-4063 AD
D1721 95KUBY0078AK J 1SS400 TE-61 AB
D1722 95KUBC0447AY J DAN217U T146
D1723 95KUBC0447AY J DAN217U T146
D1724 95KUBC0447AY J DAN217U T146
ZD951 95KUBDRT130B J Zener Diode, RD13SB-T1
ZD952 95KUBXAD8R2C J Zener Diode, RD8.2SB2-T1 AB
ZD1701 95KUBXBT2R4A J Zener Diode, RD2.4SB-T1 AB
ZD1702 95KUBXAD4R7C J Zener Diode, RD4.7SB2-T1 AD
ZD1703 95KUBXAD6R8C J Zener Diode, RD6.8SB2-T1 AB
ZD1704 95KUBXAD100C J Zener Diode, RD10SB2-T1 AD
ZD1705 95KUBXAD150A J Zener Diode, RD15SB-T1 AA
ZD1707 95KUBXAD160A J Zener Diode, RD16SB-T1 AB
ZD1708 95KUBXAD180A J Zener Diode, RD18SB-T1 AC
COILS
L951 95KUKY0015DY J Coil, SHP1055P-220A AF
L952 95KUKY0016AY J Coil, SHP1260P-180A AG
L1701 95KUKY0015BY J Coil, SHP1055P-330A AF
L1702 95KUKY0015BY J Coil, SHP1055P-330A AF
L1703 95KUKY0015BY J Coil, SHP1055P-330A AF
L1704 95KUKY0015EY J Coil, SHP1055P-680A AF
L1770 95KUKY0015AY J Coil, SHP1055P-3R3A AF
RDENCA089WJZZ
DC/DC CONVERTER UNIT
RDENCA064WJZZ
RDENCA110WJZZ
POWER SUPPLY UNIT(Continued)
SC901 95KRAE3080ZZ J Screw AB
(TU-GD10U-T/TU-45GAT)
SC901 95KRAE00027Z J Screw
(TU-45GAD)
SC902 95KRAZ3168ZB J Screw AA
(TU-GD10U-T/TU-45GAT)
SC902 95KRAA3010AC J Screw
(TU-45GAD)
SC903 95KRAZ3168ZB J Screw AA
(TU-GD10U-T/TU-45GAT)
SC903 95KRAA3010AC J Screw
(TU-45GAD)
SC904 95KRAZ3168ZB J Screw AA
(TU-GD10U-T/TU-45GAT)
SC904 95KRAA3010AC J Screw
(TU-45GAD)
SC905 95KRAZ3168ZB J Screw AA
(TU-GD10U-T/TU-45GAT)
SC905 95KRAA3010AC J Screw
(TU-45GAD)
SC906 95KRAZ3168ZB J Screw AA
(TU-GD10U-T/TU-45GAT)
SC906 95KRAA3010AC J Screw
(TU-45GAD)
SC907 95KRAZ3168ZB J Screw AA
(TU-GD10U-T/TU-45GAT)
SC907 95KRAA3010AC J Screw
(TU-45GAD)
SC908 95KRAZ3252ZB J Screw AB
(TU-GD10U-T/TU-45GAT)
SC908 95KRAA00006Z J Screw
(TU-45GAD)
