Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
205
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
INTEGRATED CIRCUITS
IC7851 VHiLM2642MT-1Y J LM2642MTCX/N0P AR
IC7852 VHiLM2642MT-1Y J LM2642MTCX/N0P AR
TRANSISTORS
Q7851 VSDTC144EKA-1Y J DTC144EKA AB
Q7852 VSDTC144EKA-1Y J DTC144EKA AB
Q7853 VSDTC144EKA-1Y J DTC144EKA AB
Q7854 VSDTC144EKA-1Y J DTC144EKA AB
Q7855 VSRSS090N03-1Y J RSS090N03 AE
Q7856 VSRSS090N03-1Y J RSS090N03 AE
Q7857 VSRSS090N03-1Y J RSS090N03 AE
Q7858 VSRSS090N03-1Y J RSS090N03 AE
Q7859 VSRSS090N03-1Y J RSS090N03 AE
Q7860 VSRSS090N03-1Y J RSS090N03 AE
Q7861 VSRSS090N03-1Y J RSS090N03 AE
Q7862 VSRSS090N03-1Y J RSS090N03 AE
Q7863 VSDTC144EKA-1Y J DTC144EKA AB
Q7864 VSDTC144EKA-1Y J DTC144EKA AB
Q7865 VSDTC144EKA-1Y J DTC144EKA AB
Q7876 VSDTC144EKA-1Y J DTC144EKA AB
CAPACITORS
C7852 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7853 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7854 RC-KZ0070TAZZY J 4.7 16V AD
C7855 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7856 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7857 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7858 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C7859 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C7860 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7861 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7862 VCCCCY1HH101JY J 100p 50V Ceramic AA
C7863 RC-KZA111WJZZY J 1 50V Ceramic AC
C7864 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7865 RC-KZA068WJZZY J 4.7 50V Ceramic AC
C7866 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7867 VCAAPE1CJ686MY J 68 16V Electrolytic AD
C7868 VCAAPE1CJ686MY J 68 16V Electrolytic AD
C7869 VCAAPE1CJ686MY J 68 16V Electrolytic AD
C7870 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7871 VCAAPE1CJ686MY J 68 16V Electrolytic AD
C7872 VCAAPE1AJ127MY J 120 10V Electrolytic AD
C7873 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7874 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7875 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7876 RC-KZ0070TAZZY J 4.7 16V Ceramic AD
C7877 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7878 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7879 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7880 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C7881 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C7882 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7883 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7884 RC-KZA111WJZZY J 1 50V Ceramic AC
C7885 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7886 RC-KZA068WJZZY J 4.7 50V Ceramic AC
C7887 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7888 VCAAPE1CJ686MY J 68 16V Electrolytic AD
C7889 VCAAPE1CJ686MY J 68 16V Electrolytic AD
C7890 VCAAPE1AJ127MY J 120 10V Electrolytic AD
C7891 VCAAPE1AJ127MY J 120 10V Electrolytic AD
C7892 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C7893 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C7894 VCKYCY1HB103KY J 0.01 50V Ceramic AA
RESISTORS
R7851 VRS-CY1JF203JY J 20k 1/16W Metal Oxide AA
R7852 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7853 VRS-CY1JF203JY J 20k 1/16W Metal Oxide AA
DUNTKC507UJ01/08/10
CS CONTROL UNIT
R5896 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R5897 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R5898 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB1704 RBLN-0064TAZZY J Ferrite Bead AB
FB1705 RBLN-0210TAZZY J Ferrite Bead AB
FB1706 RBLN-0210TAZZY J Ferrite Bead AB
FB1707 RBLN-0064TAZZY J Ferrite Bead AB
FB1712 RBLN-0210TAZZY J Ferrite Bead AB
FB1714 RBLN-0210TAZZY J Ferrite Bead AB
FB1715 RBLN-0210TAZZY J Ferrite Bead AB
FB1716 RBLN-0210TAZZY J Ferrite Bead AB
FB1718 RBLN-0210TAZZY J Ferrite Bead AB
FB1719 RBLN-0210TAZZY J Ferrite Bead AB
FB1721 RBLN-0210TAZZY J Ferrite Bead AB
FB1722 RBLN-0210TAZZY J Ferrite Bead AB
FB1724 RBLN-A005WJZZY J Ferrite Bead AA
FB5802 RBLN-0210TAZZY J Ferrite Bead AB
FB5803 RBLN-0210TAZZY J Ferrite Bead AB
FB5804 RBLN-0209TAZZY J Ferrite Bead AB
FB5805 RBLN-0209TAZZY J Ferrite Bead AB
FB5806 RBLN-0209TAZZY J Ferrite Bead AB
FB5807 RBLN-0209TAZZY J Ferrite Bead AB
FB5808 RBLN-0209TAZZY J Ferrite Bead AB
FB5809 RBLN-0209TAZZY J Ferrite Bead AB
FB5810 RBLN-0209TAZZY J Ferrite Bead AB
FB5811 RBLN-0209TAZZY J Ferrite Bead AB
FB5812 RBLN-0210TAZZY J Ferrite Bead AB
FB5813 RBLN-0210TAZZY J Ferrite Bead AB
FB5814 RBLN-0210TAZZY J Ferrite Bead AB
FB5815 RBLN-0210TAZZY J Ferrite Bead AB
LUG1701 QLUGHA002WJZZ J Lug AB
LUG1702 QLUGHA002WJZZ J Lug AB
LUG1703 QLUGHA002WJZZ J Lug AB
LUG1704 QLUGHA002WJZZ J Lug AB
P1701 QCNCMA116WJZZ J Connector, 20Pin(SP) AE
P1702 QPLGNA050WJZZ J Plug, 11Pin(DC) AC
P5801 QPLGN0056CEZZY J Plug, 6Pin AD
SC1701 QCNCWA202WJZZY J Connector, 60Pin AK
SC1702 QCNCWA202WJZZY J Connector, 60Pin AK
LHLDFA021WJZZ J Holder AC
DUNTKC506UJ01/08/10
DC/DC UNIT(Continued)
