Ref. No. Part No. ★ Description Code
206
Ref. No. Part No. ★ Description Code
TU-GD10U-T
TU-45GAD/T
LC-45GX6U/D/T
R7854 VRS-CY1JF133FY J 13k 1/16W Metal Oxide AA
R7855 VRS-CY1JF133FY J 13k 1/16W Metal Oxide AA
R7856 VRS-CY1JF224JY J 220k 1/16W Metal Oxide AA
R7857 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7858 VRS-CY1JF4R7JY J 4.7 1/16W Metal Oxide AA
R7859 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7860 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7861 VRS-CY1JF4R7JY J 4.7 1/16W Metal Oxide AA
R7862 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7863 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7864 VRS-CY1JF4R7JY J 4.7 1/16W Metal Oxide AA
R7865 VRS-CY1JF104FY J 100k 1/16W Metal Oxide AA
R7866 VRS-CY1JF473FY J 47k 1/16W Metal Oxide AA
R7867 VRS-CY1JF183FY J 18k 1/16W Metal Oxide AA
R7868 VRS-CY1JF203FY J 20k 1/16W Metal Oxide AA
R7869 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7870 VRS-CY1JF203FY J 20k 1/16W Metal Oxide AA
R7871 VRS-CY1JF104FY J 100k 1/16W Metal Oxide AA
R7872 VRS-CY1JF474FY J 470k 1/16W Metal Oxide AA
R7873 VRS-CY1JF203JY J 20k 1/16W Metal Oxide AA
R7874 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7875 VRS-CY1JF203JY J 20k 1/16W Metal Oxide AA
R7876 VRS-CY1JF133FY J 13k 1/16W Metal Oxide AA
R7877 VRS-CY1JF133FY J 13k 1/16W Metal Oxide AA
R7878 VRS-CY1JF224JY J 220k 1/16W Metal Oxide AA
R7879 VRS-CY1JF4R7JY J 4.7 1/16W Metal Oxide AA
R7880 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7881 VRS-CY1JF4R7JY J 4.7 1/16W Metal Oxide AA
R7882 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7883 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7884 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7885 VRS-CY1JF4R7JY J 4.7 1/16W Metal Oxide AA
R7886 VRS-CY1JF823FY J 82k 1/16W Metal Oxide AA
R7887 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R7888 VRS-CY1JF203FY J 20k 1/16W Metal Oxide AA
R7889 VRS-CY1JF224FY J 220k 1/16W Metal Oxide AA
R7890 VRS-CY1JF683FY J 68k 1/16W Metal Oxide AA
R7891 VRS-CY1JF272FY J 2.7k 1/16W Metal Oxide AA
R7892 VRS-CY1JF203FY J 20k 1/16W Metal Oxide AA
R7893 VRS-CY1JF224FY J 220k 1/16W Metal Oxide AA
R7894 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7895 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R7896 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB7851 RBLN-0064TAZZY J Ferrite Bead AB
FB7852 RBLN-0064TAZZY J Ferrite Bead AB
FB7853 RBLN-0064TAZZY J Ferrite Bead AB
FB7854 RBLN-0064TAZZY J Ferrite Bead AB
FB7855 RBLN-0064TAZZY J Ferrite Bead AB
FB7856 RBLN-0064TAZZY J Ferrite Bead AB
FB7857 RBLN-0064TAZZY J Ferrite Bead AB
FB7858 RBLN-0064TAZZY J Ferrite Bead AB
P7851 QCNCMA202WJZZY J Connector, 60Pin AK
P7852 QCNCMA202WJZZY J Connector, 60Pin AK
DUNTKC507UJ01/08/10
CS CONTROL UNIT(Continued)
DIODES
D153 RH-EXA092WJZZY J Zener Diode, 12V AB
D154 RH-EXA092WJZZY J Zener Diode, 12V AB
D155 RH-EXA092WJZZY J Zener Diode, 12V AB
RESISTORS
R154 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R155 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R156 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
SWITCHES
S158 QSW-K0108CEZZY J Switch, CH-UP AD
S159 QSW-K0108CEZZY J Switch, CH-DOWN AD
S160 QSW-K0108CEZZY J Switch, INPUT AD
S161 QSW-K0108CEZZY J Switch, VOL-UP AD
S162 QSW-K0108CEZZY J Switch, VOL-DOWN AD
S163 QSW-K0108CEZZY J Switch, POWER AD
MISCELLANEOUS PART
P154 QPLGNA060WJZZ J Plug, 6Pin(KM) AC
DUNTKC508UJ01/08/10
KEY UNIT

Sharp TU-GD10U-T Specifications

General

Brand	Sharp
Model	TU-GD10U-T
Category	LCD TV
Language	English
