Sharp VL-A10U User Manual

VL-E990E
VL-A10U/UC/UA/UW/T/K
VL-AH30U/UC/T
10
<8. Removal of the Lithium PWB>
(1) Remove the connector of the speaker from the Main PWB.
(b)
<7. Removal of the speaker cover>
Inverter transformer
Main PWB
Connector
Lithium PWB
LCD unit
(b)
Battery terminal
unit
<6. Removal of the tilt unit>
Tilt frame V
Main PWB
Connector
Tilt frame C
Connector
<9. Disassembly of the frame V>
(e)
Mechanism unit
(e)
(e)
A
D
C
B
E
F
C
<10. Removal of the cassette compartment lid>
(1) Using the slotted precision screwdriver, push and turn the
two claws (C and D) which fasten the cassette compartment
lid, and the cassette compartment lid will be removed from
the hook area of the cassette component.
(2) Turning the cassette compartment lid in the arrow direction,
lift it, and the claws A and B will be disengaged to remove the
cassette compartment lid.
Note:
Take care to prevent breaking the claws of the cassette com-
partment lid.
(2) Remove the screw ((b)LX-HZ0018TAFF) fixing the speaker
cover.
(3) Move the speaker holder in the direction of the arrow to
remove it.
B
D
Frame V
Connector
(1) Remove three screws ((e)LX-BZ0191TAFD) and one con-
nector, and remove the frame V from the main body.
(1) Disconnect three connectors.
Remove the tilt unit from the cabinet of the main body.
(3) Remove two screws ((b)LX-HZ0018TAFF) and two connec-
tors, and remove the LCD unit (with inverter) from the main
body.
(1) Remove the connector of the Lithium PWB from the Main
PWB.
(2) Move the lithium unit in the direction of the arrow.
