95
VL-E990E
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
VL-A10U/UC/UA/UW/T/K
VL-AH30U/UC/T
11.REPLACEMENT PARTS LIST/
EXPLODED VIEWS
ELECTRICAL PARTS LIST
Parts marked with " å " are important for maintaining the safety of the
set. Be sure to replace these parts with specified ones for maintaining
the safety and performance of the set.
Les pièces marquéss " å " sont importantes pour maintenir la sècurité
de l'appareil. Ne remplacer ces pieces que par des pièces dont le
numéro est spécifié pour maintenir la sécurité et protéger le bon
fonctinnement de l'appareil.
" HOW TO ORDER REPLACEMENT PARTS "
in USA: Contact your nearest SHARP Parts Distributor. For
location of SHARP Parts Distributor,
Call Toll-free 1-IBE800-SHARP
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100.
★MARK : SPARE PARTS-DELIVERY SECTION:ALL JAPAN
To have your order filled promptly and correctly, please furnish
the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. PRICE CODE
å MARK: SAFETY RELATED PARTS
å PIECES: RELATIVES A LA SECURITE
PWB ASSEMBLY IS NOT REPLACEMENT ITEM
L'ASSEMBLANGE P.C.I. EST UN ARTICLE NON REMPLACABLE
Ref. No. Part No. ★ Description Code
DUNTK2949QA00(VL-AH30U/UC)
DUNTK2949QA03(VL-A10U/UC/UA/UW)
DUNTK2949QA05(VL-A10T)
DUNTK2949QA06(VL-AH30T)
DUNTK2949QA12(VL-A10K)
VCR UNIT
INTEGRATED CIRCUITS
IC151 VHiCXD2310A-1 CXD2310A, A/D Converter AV
* IC401 RH-iX0769TAZZ IX0769TA, Integrated DSP BL
or
RH-iX0788TAZZ IX0788TA, Integrated DSP BB
IC601 VHiLA7458W/-1 LA7458W, Sig Process AT
IC701 VHiS81330HG-1 S81330HG, 3V REG AF
IC702 VHiRN5VD25A-1 RN5VD25A, 2.5V DET AE
IC704 VHiRS5C313/-1 RS5C313, Clock AL
IC705 VHiM24C08W6-1 M24C08W6, E
2
PROM AH
IC706 RH-iX0756TAZZ IX0756TA, System/Servo
Control(A10T/AH30T)
IC706 RH-iX0759TAZZ IX0759TA, System/Servo BC
Control(A10U/UC/UA/UW/AH30U/UC)
IC707 RH-iX0766TAZZ IX0766TA, OSD.IC
(A10T/AH30T)
IC707 RH-iX0768TAZZ IX0768TA, OSD.IC AP
(A10U/UC/UA/UW/AH30U/UC)
IC708 VHiTA75S01F-1 TA75S01F, Amp AD
IC710 VHiTC4W53U/-1 TC4W53U AF
IC711 VHiTC4W53U/-1 TC4W53U AF
IC712 VHiTC7W74U/-1 TC7W74U AD
IC800 VHiMM1323XV-1 MM1323XV, LCD Interface AN
IC900 VHiMB3881//-1 MB3881, Power Control IC AT
IC902 VHiBU4051FV-1 BU4051FV, Multiplexer AF
IC903 VHiNJM2904M-1 NJM2904M, 3.1V/2.5V AE
Error Amp
IC904 VHiTA75S01F-1 TA75S01F, Amp AD
IC1451 VHiTK15440M-1 TK15440M, Driver AF
IC2701 VHiMB88344F-1 MB88344F, D/A Converter AV
IC2901 VHiMM1332GF-1 MM1332GF, Charge Control AH
IC2902 VHiNJU7012F-1 NJU7012F, AE
Over Current Detector
IC3800 VHiNJM2107F-1 NJM2107F, AFC LPF AE
IC3801 VHiLZ9GH16/-1 LZ9GH16, LCD Controler AP
TRANSISTORS
Q403 VS2SA1873Y/-1 2SA1873Y AC
Q406 VS2SA1989R/-1 2SA1989R AB
Q407 VS2SA1989R/-1 2SA1989R AB
Q409 VSHN1B04FU/-1 HN1B04FU AC
Q410 VS2SA1989R/-1 2SA1989R AB
Q601 VS2SA1362GR-1 2SA1362GR AC
Q602 VSRT1N441U/-1 RT1N441U AB
Q603 VS2SC5383F/-1 2SC5383F AB
Q704 VSHN1B04FU/-1 HN1B04FU AC
Q705 VSHN2C01FU/-1 HN2C01FU AC
Q707 VSHN1C01FU/-1 HN1C01FU AC
Q708 VSRN2904///-1 RN2904 AC
Q709 VSHN1C01FU/-1 HN1C01FU AC
Q901 VS2SA2010//-1 2SA2010 AD
Q903 VS2SA1989R/-1 2SA1989R AB
Q904 VS2SA1362GR-1 2SA1362GR AC
Q905 VS2SA1989R/-1 2SA1989R AB
Q906 VS2SA2010//-1 2SA2010 AD
Q908 VS2SA1362GR-1 2SA1362GR AC
Q911 VSCPH3215//-1 CPH3215 AD
Q912 VS2SA1989R/-1 2SA1989R AB
Q913 VSRT1N441U/-1 RT1N441U AB
Q913 VS2SC5383F/-1 2SC5383F(A10T) AB
Q914 VSRT1N441U/-1 RT1N441U AB
Q916 VSRN4983///-1 RN4983 AC
Q917 VSRN4983///-1 RN4983 AC
Q918 VSRN4983///-1 RN4983 AC
Q919 VSCPH6702//-1 CPH6702 AD
Q921 VSCPH6702//-1 CPH6702 AD
Q922 VSCPH6702//-1 CPH6702 AD
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTK2949QA00 VCR Unit —
(VL-AH30U/UC)
DUNTK2949QA03 VCR Unit —
(VL-A10U/UC/UA/UW)
DUNTK2949QA05 VCR Unit(VL-A10T) —
DUNTK2949QA06 VCR Unit(VL-AH30T) —
DUNTK2949QA12 VCR Unit(VL-A10K) —
DUNTK2934QA00 CAMERA Unit —
DUNTK2936QA00 HEAD AMP Unit —
DUNTK2800PM03 CCD Unit —
TUNER AND ASSEMBLY UNITS
RUNTK0352TAZZ AV Jack Unit AS
RUNTK0353TAZZ VCR Operation Unit AS
(VL-A10U/UC/UA/UW/K/AH30U/
UC)
RUNTK0369TAZZ VCR Operation Unit
(VL-A10T/AH30T)
RUNTK0354TAZZ Lithium Battery Unit AF
RUNTK0356TAZZ 6-cell Detection Unit
IC401 L918
RH-IX0769TAZZ
⇔
RC-iLP0271TAZZ
RH-IX0788TAZZ
⇔
RC-iLP0287TAZZ
* IC401 varies according to L918. (Be sure to make IC401 and L918 a pairing.)
