Sharp VL-A10U User Manual

103
VL-E990E
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
VL-A10U/UC/UA/UW/T/K
VL-AH30U/UC/T
R8462 VRS-CZ1JF183J 18k 1/16W Metal Oxide AA
R8463 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R8464 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R8467 VRS-CZ1JF331D 330 1/16W Metal Oxide AA
R9410 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R9919 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R9921 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
PSLDM3238TAFW Shield AC
PSLDM3239TAFW Shield AC
PSLDM3344TAFW Shield
PZETV0412TAZZ Insulator AD
CN701 QPLGN0263TAZZ Plug, 2Pin AB
CN702 QPLGN0264TAZZ Plug, 2Pin AC
CN703 QSOCN0860TAZZ Socket, 8Pin AE
CN3601 QSOCN1207REN1 Socket, 12Pin AD
CN3800 QSOCN2471TAZZ Socket, 24Pin AE
CN7401 QCNCM7068TAZZ Connector, 70Pin AG
CN9401 QSOCN1860TAZZ Socket, 18Pin AE
å CP901 QFS-L2526TAZZ Fuse, 2.5A 16V AC
å CP902 QFS-L2526TAZZ Fuse, 2.5A 16V AC
å CP903 QFS-L2526TAZZ Fuse, 2.5A 16V AC
FB151 RBLN-0107TAZZ Balun, BLN-0107TA AB
FB152 RBLN-0107TAZZ Balun, BLN-0107TA AB
FB3800 RBLN-0028TAZZ Balun, BLN-0028TA AB
P601 QPLGN0263TAZZ Plug, 2Pin AB
P902 QPLGN0364TAZZ Plug, 3Pin AC
P2901 QPLGN0664TAZZ Plug, 6Pin AD
P2902 QPLGN0764TAZZ Plug, 7Pin AD
SC151 QSOCN2071TAZZ Socket, 20Pin AD
SC152 QSOCN2471TAZZ Socket, 24Pin AE
SC901 QSOCN0772TAZZ Socket, 7Pin AC
DUNTK2934QA00
CAMERA UNIT
INTEGRATED CIRCUITS
IC11 VHiUPD16510-1 UPD16510, V-Driver AR
IC12 VHiLR38590/-1 LR38590, Timing AR
Generator
IC101 VHiCXA2006Q-1 CXA2006Q, CDS/AGC AV
IC102 VHiMB88146A-1 MB88146A, D/A Converter AH
IC551 VHiUPD16835-1 UPD16835 AM
IC552 VHiNJM2902V-1 NJM2902V, OP-Amp AD
IC553 VHiNJM3414V-1 NJM3414V, OP-Amp AF
IC554 VHiTVHC74T/-1 TVHC74T AF
TRANSISTORS
Q11 VSHN2C01FU/-1 N2C01FU AC
Q12 VS2SA1989R/-1 2SA1989R AB
Q13 VS2SC5383F/-1 2SC5383F AB
Q14 VS2SC5383F/-1 2SC5383F AB
Q15 VS2SA1989R/-1 2SA1989R AB
Q551 VSRN1902///-1 RN1902 AC
DIODE
D551 VHDMA132K//-1 DMA132K AA
PACKAGED CIRCUIT
X11 RCRSC0172TAZZ Crystal, CRSC0172TA
TRANSFORMERS
L11 VPBWM100KR50N Peaking, 10µHAC
L12 VPBWM470K2R6N Peaking, 47µHAC
L13 VPD9M470J6R6N Peaking, 47µHAC
L101 VPBWM100KR50N Peaking, 10µHAC
L551 VPBWM220K1R2N Peaking, 22µHAC
L553 VPBWM100KR50N Peaking, 10µHAC
CAPACITORS
C11 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C12 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C13 VCKYCY1HB103K 0.01 50V Ceramic AA
C14 VCSATA1DJ475M 4.7 20V Tantalum AC
C15 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C16 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C17 VCSATE1VJ335M 3.3 35V Tantalum AD
C18 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C20 VCSATA1AJ106M 10 10V Tantalum AC
C21 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C22 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C23 VCSATA1AJ106M 10 10V Tantalum AC
C24 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C25 VCKYCZ1HB102K 1000p 50V Ceramic AB
C26 VCSATA1AJ106M 10 10V Tantalum AC
C27 VCKYCZ1CB103K 0.01 16V Ceramic AB
C28 VCCCCY1HH270G 27p 50V Ceramic
C29 VCSATE1VJ335M 3.3 35V Tantalum AD
C30 VCKYCZ1HB102K 1000p 50V Ceramic AB
C33 VCCCCY1HH360G 36p 50V Ceramic
C34 VCCCCY1HH180G 18p 50V Ceramic
C35 VCKYCZ1CB103K 0.01 16V Ceramic AB
C36 VCKYCZ1CB103K 0.01 16V Ceramic AB
C37 VCSATA1AJ106M 10 10V Tantalum AC
C38 VCKYCY0JB105K 1 6.3V Ceramic AC
C101 VCKYTV1AB105K 1 10V Ceramic AD
C102 VCKYTV1AB105K 1 10V Ceramic AD
C103 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C104 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C105 VCKYCZ1EF223Z 0.022 25V Ceramic AB
C106 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C107 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C108 VCSATA1AJ106M 10 10V Tantalum AC
C109 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C110 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C111 VCSATA1AJ106M 10 10V Tantalum AC
C112 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C113 VCSATA1AJ106M 10 10V Tantalum AC
C114 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C115 VCSATA1AJ106M 10 10V Tantalum AC
C116 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C117 VCCCCZ1HH150J 15p 50V Ceramic AB
C118 VCKYCZ1AB104K 0.1 10V Ceramic AB
C119 VCKYCZ1HB471K 470p 50V Ceramic AB
C120 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C551 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C552 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C553 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C554 VCCCCZ1HH330J 33p 50V Ceramic AB
C555 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C556 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C558 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C559 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C560 VCSATE1CJ156M 15 16V Tantalum AD
C561 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C562 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C563 VCSATA1AJ106M 10 10V Tantalum AC
C565 VCSATA1AJ106M 10 10V Tantalum AC
C566 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C567 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C568 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C569 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C570 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C571 VCKYCZ1HF103Z 0.01 50V Ceramic AB
C572 VCCCCZ1HH151J 150p 50V Ceramic AB
C573 VCKYCY1AF105Z 1 10V Ceramic AC
C574 VCKYCZ1HF103Z 0.01 50V Ceramic AB
RESISTORS
R11 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R14 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R15 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R17 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R18 VRS-CZ1JF102J 1k 1/16W Metal Oxide AA
R19 VRS-CZ1JF222J 2.2k 1/16W Metal Oxide AA
R20 VRS-CZ1JF822J 8.2k 1/16W Metal Oxide AA
