4-2
VL-E610S/VL-E610H
VL-E660S/VL-E96E
VL-E98E
No. Name Part No. Code Configuration Model, Uses
Remarks
10 Alignment tape VR2DBOPS BT
11 Tension Band and JiGDRiVERMX7U2 BN
Plate Adjusting Jig
12 Others
(1) Calipers.
(2) High-precision screwdrivers (Phillips head, slotted head)
(3) Radio pliers (with thin jaws)
(4) A pair of tweezers
TAPE CONTENTS
VIDEO IMAGE AUDIO TIME
MONOSCOPE L-CH 400Hz 30MIN
R-CH 1,000Hz
4-1-2. Parts for periodic inspection and maintenance.
No. Name Part No. Code Configuration Model, Uses
1 Oil • Cosmo Oil Co., Ltd.
1) COSMOHYDRO HV100
2 Cleaning paper JiGDUSPER AP • Dusper ∑ (Sigma)
(Ozu Co., Ltd.)
3 Superfine swab • Comercially available
item.
4 Grease • Dow Coaning
Morycoat YM-103/X5-6020
5 Screw locking agent • Three Bond
(1401B)
6 Cleaning liquid
(Industrial-use ethyl alcohol)
To Next Page
