Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
10
VL-E630S/VL-E630H
VL-E680S/VL-E97E
VL-E99E
VL-E630S/VL-E630H
VL-E680S/VL-E97E
VL-E99E
—— End of Mechanism Parts ——
374 TLABH0196TAZZ Caution Label AB
375 PSHEM0014GEZZ Counter Balance AC
376 PSHEP0013GEZZ Interruption Sheet AC
200 XAPSF17P03200 Screw M1.7x3.2 AA
201 LX-XZ3036GEFP Screw M2.0x6.0 AD
202 LX-BZ3175GEFN Screw M1.7x4.0 AC
203 LX-BZ3163GEFN Screw M1.7x2.5 AC
204 LX-HZ3074GEFN Screw M1.7x5.3 S Tight AA
205 LX-BZ3177GEFF Screw M1.4x1.5 AB
206 LX-HZ3132GEFF Screw M1.4x1.5xD3.5 AB
207 LX-BZ3178GEZZ Screw M1.4x1.5xD4.0 AD
208 LX-HZ3083GEFF Screw M1.4x2.5 S Tight AB
209 LX-HZ3077GEFN Screw M1.4x3.0 S Tight AA
211 LX-HZ3084GEFF Screw M1.4x4.0 S Tight AC
212 LX-HZ3116GEFD Screw M1.4x3.2 S Tight AB
213 LX-NZ3053GEZZ Screw M1.4 Nut AC
214 LX-WZ1076GE02 Washer D0.8xD3.0x0.2t AA
Plastics
215 LX-WZ1075GE02 Washer D2.1xD5.0x0.25t AA
Plastics
216 XWHJZ12-02040 Washer D1.2xD4.0x0.25t AC
Plastics
300 LCHSM0163GEZZ Main Chassis Ass'y AW
301 NGERH1280GEZZ Main Cam AD
302 NGERH1281GEZZ Sub-Cam AD
303 MLEVF0470GEFW Eject Lever AD
304 MLEVF0492GEFW M Function Lever AF
305 LHLDZ1966GEZZ L Block Holder AD
306 NGERW1064GEZZ Worm Pulley AC
307 NGERW1065GEZZ Worm AD
308 NGERH1282GEZZ Worm Wheel AC
309 NGERH1283GEZZ Lo Relay Gear AC
310 MARMM0126GEZZ S Lo Arm Ass'y AF
311 MARMM0128GEZZ T Lo Arm Ass'y AG
312 LANGA0069GEFW S Lo Arm Retainer AD
313 PGiDM0146GEZZ Sup Rail AD
314 PGiDM0171GEZZ Tu Rail AD
315 NGERH1284GEZZ Sup Lo Gear AC
316 NGERH1285GEZZ Tu Lo Gear AC
317 MSPRD0167GEZZ S Lo Arm Double-Acting AE
Spring
318 MSPRT0407GEZZ T Lo Arm Double-Acting AC
Spring
319 MLEVP0310GEZZ HC Lever Ass'y AD
321 MSLiF0074GEFW Ten Arm Operation Lever AD
322 PGiDM0148GEZZ Ten Arm Guide AC
323 NGERH3045GEFW Segment Gear AD
324 MLEVF0472GEZZ Tu Guide Ass'y AC
325 PGiDP0027GEZZ Tu Guide AE
326 MSPRC0183GEZZ Tu Guide Spring AA
327 MSPRC0184GEZZ Si Roller Spring AA
328 MSPRC0208GEZZ Tu Guide Lever Spring AC
329 LCHSS0049GEZZ Slide Chassis Ass'y AP
330 MLEVF0495GEZZ Ten Arm Ass'y AC
331 LBNDK3023GEZZ Ten Band Ass'y AF
332 NiDR-0016GEZZ Swing Gear Ass'y AF
333 NGERH1286GEZZ Driving Gear AC
334 NGERH1287GEZZ Pulley Gear AD
335 NPLYV0157GEZZ Relay Pulley AD
336 MLEVP0284GEZZ S Brake AC
337 NGERH1288GEZZ Tu Brake Gear AC
338 MLEVP0285GEZZ Tu Main Brake AC
339 MLEVP0286GEZZ Tu Sub-Brake AC
340 MSPRD0169GEZZ Tu Brake Spring AD
341 LHLDZ2053GEZZ Light Guide Holder Ass'y AF
342 LANGG9102GEFW Down Guide AF
343 MSPRT0408GEZZ Tension Spring AD
344 MSPRD0186GEZZ S Brake Spring AD
345 CDRMU0032GE02 Upper Drum Ass'y BF
346 PGiDM0154GEZZ Tape Guide AB
348 QBRSK0039GEZZ Earth Spring AD
349 PGiDM0143GEZZ Drum Base AG
350 DDRML0020HE01 Lower Drum Ass'y AY
351 RMOTP1137GEZZ Drum Motor AS
352 PSPAQ0010GEZZ Gap Adjusting Shim AC
353 NRTR-0096GEZZ R Tr Rotor Ass'y AP
354 MSPRC0209GEZZ Gr Adjusting Spring AC
355 LPOLM0058GEZZ S Pole Base AK
356 LPOLM0059GEZZ T Pole Base AK
357 NDAiV1071GEZZ Sup Reel Support AG
358 NDAiV1072GEZZ Tu Reel Support AG
359 MLEVF0517GEZZ Pinch Lever Ass'y AS
360 NBLTT0012GEZZ Timing Belt S AE
361 NBLTT0013GEZZ Timing Belt L AE
362 NROLP0108GEZZ Guide Roller Ass'y AG
363 NROLP0109GEZZ Si Roller Ass'y AH
364 QPWBH5428GEZZ Mode FPC AG
365 CPWBN5639GE01 Sensor Ass'y AV
366 QSW-M0050GEZZ Recognition SW AD
367 RDTCH0037GEZZ Dew Sensor AF
368 RMOTV1019GEZZ Cap. Motor AZ
369 RMOTM1075GEZZ Load. Motor AL
370 QSW-R0038GEZZ Mode SW AG
372 RAMP-0017TAN1 H/A PWB AY
MECHANISM PARTS
