VL-E630S/VL-E630H
VL-E680S/VL-E97E
VL-E99E
VL-E630S/VL-E630H
VL-E680S/VL-E97E
VL-E99E
2
1. SPECIFICATIONS
Signal System: PAL standard
Recording System: 2 rotary heads, helical scanning system
Cassette: 8 mm video tape, MP type
Recording/Playback Time: 120 minutes (P5-120)
Tape Speed: 20.051 mm/second
Pickup Device: 1/4" (6.4mm, effective size: 4.5 mm) CCD image sensor with approx.
320,000 pixels including optical black
Lens: 16 × power zoom lens (F1.4, f=4.0-64.0 mm) and full-range auto focus
Lens Filter Diameter: 46 mm
Monitor: 3" (7.5 cm)—full-color LCD screen (TFT active matrix)
Microphone: Electret monaural microphone
Color Temperature Compensation: Auto white balance
Minimum Illumination: 0.8 lux (5 lux measured by EIA standard) (with gain-up, F1.4)
Video Output Level: 1.0 Vp-p 75-ohm unbalanced
Audio Output Level: –8 dBs, impedance less than 2.2 kohms
Speaker Output: 200 mW
Power Requirement: DC 3.6V
Power Consumption:
E630S/E630H/E97E:4.8W (during camera recording in full auto mode
with zoom motor off, and backlight in normal mode)
E680S/E99E:4.9W (during camera recording in full auto mode with zoom
motor off, Extend Zoom, DIS and Snapshot functions off, and backlight
in normal mode)
Operating Temperature: 0°C to + 40°C (32°F to 104°F)
Operating Humidity: 30% to 80%
Storage Temperature: –20°C to +60°C (–4°F to 140°F)
Dimensions (approx.): 182 mm (W) × 109 mm (H) × 99 mm (D)
Weight (approx.): 690g
(without battery pack, lithium battery, video cassette, and lens cap)
AC Adapter/Battery Charger
UADP-0280TAZZ
UADP-0281TAZZ(VL-E630H)
Power Requirement: AC 110-240 V, 50/60 Hz
DC Output: 4.5 V
Power Consumption: 16 W
Dimensions (approx.): 75 mm (W) × 51 mm (H) ×
130 mm (D)
Weight (approx.): 220 g
Specifications are subject to change without notice.
Battery Pack BT-H22
DC Output: 3.6V
Dimensions (approx.): 54 mm (W) × 19 mm (H) ×
56 mm (D)]
Weight (approx.): 0.30 lbs (136 g)
When the IC702 has been replaced, make the following settings and adjustments.
3. Setting up the V ADJ mode as follows.
* After press the CONTINUE key, press the VCR ADJ key on service remote control (RRMCG0033TASA).
E630S E630H E680S E97EX E99EX
address data data data data data
02 0A 0A 0A 0B 0B
0A F5 F5 F5 F4 F4
03 80 88 B0 88 FA
0B 7F 77 4F 77 05
05 00 00 00 40 40
0D FF FF FF BF BF
01 00 00 00 00 00
04 00 00 00 00 00
3. DISASSEMBLY OF THE SET
3-4. INITIAL SETTING OF E
2
PROM IC
3-4-2. IC702 (E
2
PROM)
