Sharp VL-E630S User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13
VL-E630S/VL-E630H
VL-E680S/VL-E97E
VL-E99E
VL-E630S/VL-E630H
VL-E680S/VL-E97E
VL-E99E
17 TLABM1918TAZZ Model Label(VL-E97EX) AD
17 TLABM1917TAZZ Model Label(VL-E97EW) AD
17 TLABM1927TAZZ Model Label(VL-E99E) AD
17 TLABM1929TAZZ Model Label(VL-E99EW) AD
18 CLNSA0127TA01 Lens Unit BS
19 GFTAC1241TASA Cassette Compartment AD
Cover
20 DUNTK2783QA09 VCR Unit(VL-E630S) —
20 DUNTK2783QA10 VCR Unit(VL-E630H) —
20 DUNTK2783QA11 VCR Unit(VL-E97E) —
20 DUNTK2783QA12 VCR Unit(VL-E680S) —
20 DUNTK2783QA13 VCR Unit(VL-E99E) —
21 DUNTK2785QA03 CAMERA Unit(VL-E630S/H) —
21 DUNTK2785QA04 CAMERA Unit(VL-E97E) —
21 DUNTK2785QA05 CAMERA Unit(VL-E680S) —
21 DUNTK2785QA06 CAMERA Unit(VL-E99E) —
22 QPWBH2814TAZZ Tilt FPC AQ
23 LHLDW1038TA00 FPC Holder AC
24 QSW-Z0286TAZZ VCR Operation Unit AR
25 QTANZ0129TAZZ Battery Terminal Unit AG
26 QSW-Z0285TAZZ Power Unit AR
27 LHLDZ1452TAZZ Power Lock Holder AC
28 MSPRC0083TAFJ Power Lock Spring AA
29 JBTN-0277TASA Power Button AD
30 LHLDZ1451TAZZ Power Holder AC
31 JKNBP0152TASA Power Knob AD
32 JKNBP0153TASA Zoom Knob AD
33 LHLDZ1453TASA Zoom Knob Holder AD
34 JKNBP0154TASA Open Knob AC
35 PSPAZ0191TAZZ Spacer AA
36 RMiCC0079TAZZ Microphone AM
37 MSPRT0034TAFJ Lid Lock Spring AC
38 LHLDZ1454TA00 VCR Lid Lock AD
39 NSFTZ0084TAFW VCR Lid Shaft AD
40 PSPAZ0192TAZZ Microphone Lead Spacer AD
41 LHLDZ1450TAZZ Speaker Holder AC
42 VSP0020P-94WN Speaker AL
43 PSPAG0103TAZZ Speaker Spacer AC
44 PCOVP9062TAZZ Speaker Mesh AB
45 PSPAG0095TAZZ VCR Lid Cushion AA
46 GCOVA3056TAKA Speaker Cover AE
47 ZTAPEZ800020E Tape —
48 QSW-Z0284TAZZ Turn/Eject SW AH
49 MLEVP0031TAZZ Eject Lever AC
50 LANGK0399TAFW Tripod Angle Ass’y AK
51 PSHEP0074TAZZ Microphone Lead Sheet AB
52 QJAKZ0071TAZZ Jack Unit AS
53 PSPAG0084TA00 Front Group Frame AD
Rubber
54 GCOVA3057TAKA Microphone Cover AG
55 QPWBH2815TAZZ CCD FPC AS
a LX-HZ0018TAFN M2x6 Tapping, Silver AA
b LX-HZ0018TAFF M2x6 Tapping, Black AA
c LX-HZ0045TAFN M2x4 Tapping, Silver AA
d XiPSF20P04000 M2x4 Small Screw, Black AA
Zinc Plating
e LX-BZ0191TAFD M2 Special Screw AC
f XiPSD20P03000 M2x3 Screw AA
g LX-UZ0016TAFD M2x5 Special Screw AA
h LX-BZ0200TAFD M2x7 Special Screw AB
i XiPSN20P04000 M2x4 Small Screw, Silver AA
j LX-HZ0063TAFC M1.7x6 Tapping, Silver AA
—— End of Cabinet Parts ——
CABINET PARTS LIST
1 DCABA6183TAK1 V Frame Service AL
1-2 PSPAG0095TAZZ VCR Lid Cushion AA
1-3 TLABH0355TAZZ Lithium Exchange Label AB
1-4 LHLDB1027TAZZ Lithium Holder AD
2 DCABB6183TAK5 L Cabinet Service AS
2-2 QEARP0233TAFJ LCD Earth Sheet AE
2-3 TLABH0318TAZZ Facing Recording Caution AB
Label
2-4 GCOVH1226TASA Jack Cover AD
2-5 GCOVA1535TAZZ Remote Control Receptor AD
Cover
2-6 ZTAPEZ800020E Tape —
3 CCABC6090TAK2 Camera Front Cabinet AT
(VL-E630S/H/E97E)
3 CCABC6091TAK4 Camera Front Cabinet AT
(VL-E99E)
3 CCABC6093TAK4 Camera Front Cabinet
(VL-E680S)
3-2 GCOVA1539TASB Lens Hood AK
4 DCABD6090TAK2 Camera Rear Cabinet AQ
(VL-E630S/H/E97E)
4 DCABD6088TAK4 Camera Rear Cabinet AS
(VL-E680S/E99E)
4-2 JBTN-0276TASA Camera Button AD
5 DFTAC1271TAK2 VCR Lid Service AU
(VL-E630S/H)
5 DFTAC1272TAK2 VCR Lid Service
(VL-E680S)
5 DFTAC1274TAK1 VCR Lid Service AU
(VL-E97E)
5 DFTAC1275TAK1 VCR Lid Service
(VL-E99E)
5-2 HBDGS0056TASA LCD Badge AE
5-3 LANGK0428TAFW VCR Lid Reinforcing Angle AG
5-4 LANGK0400TAFW Eject Fitting AD
5-5 PSPAZ0193TAZZ VCR Lid Sheet AC
5-6 MSPRD0047TAFJ VCR Lid Spring AD
6 CCOVA1536TAK7 KS Side Cover AT
6-2 NSFTZ0049TAFW Battery Lid Axle AC
6-3 MSPRD0050TAFJ Battery Lid Spring AC
6-5 GFTAB1066TAKA Battery Lid AE
6-6 HDECP0045TASA Battery Decoration Plate AC
6-7 LHLDZ1448TA00 Battery Intermediate Lock AC
6-8 MSPRC0103TAFJ Battery Intermediate Lock AD
Spring
6-9 MSPRC0102TAFJ Battery Lock Lever Spring AA
6-10 MLEVP0030TASA Battery Lid Open/Close AC
Lever
6-11 LHLDZ1449TAZZ Battery Lock Holder AC
6-12 MLEVP0029TASA Battery Lock Lever AC
6-13 MSPRC0101TAFJ Battery Push-out Spring AD
6-14 LHLDZ1445TAZZ Lens Holder AD
6-15 LANGK0398TA00 Battery Lid Angle Fitting AH
6-16 UBNDT0104TAZZ Hand Strap AM
7 DCOVA1538TAK1 Tilt Ass’y AU
7-2 PSPAZ0190TAZZ Tilt Spacer AE
7-3 GCOVA1537TAKA Tilt Frame V AL
7-4 PSPAZ0189TAZZ Rotation Spacer AD
7-5 LANGH0071TAFW Stopper Fitting AD
8 LHLDZ1446TAZZ LCD Holder AG
A PSHEP0044TAZZ Reflection Polarizing Sheet AG
9 PSHEP0045TAZZ Diffusion Sheet AD
10 PSHEP0044TAZZ Prism Sheet AG
11 PGiDM0025TAZZ Light Guide Plate AG
12 PMiR-0021TAZZ Reflection Sheet AC
å 13 CLMPV0043TA02 Lamp Inverter Unit AZ
14 CPNLC0032RM01 LCD Panel BZ
15 PZETV03A3TAZZ LCD Glass Retaining AA
17 TLABM1914TAZZ Model Label(VL-E630S) AD
17 TLABM1915TAZZ Model Label(VL-E630H) AD
17 TLABM1926TAZZ Model Label(VL-E680S) AD
17 TLABM1916TAZZ Model Label(VL-E97E) AD
