8-5. Reassembly
8-5-1. Reassembly in side of the main chassis.
Note) Numbers before part names are given as a guide to the order of assembly.
As for greasing/oiling/cleaning places refer to the attached drawings (Grease/Oil application Fig. 1, 2).
1.
Groove grease
2.
(2) Mechanism fixing angle
assembly (Rear surface)
Note) The numbers following
A and B indicate the
screw tightening order.
Item Tightening torque Quantity
A S Tight · M1.4 x L3 70mN·m 3
B S Tight · M1.4 x L2 70mN·m 6
Item Tightening torque Quantity
B S Tight · M1.4 x L2 70mN·m 1
C CWø1.2-ø3.0-t0.25 2
3.
(6) AHC cam
C
C
Cam groove grease
Groove
grease
B
(7) T arm
control lever
(3) Main cam
To cam
groove
To cam groove
(8) AHC control lever
D
D
B
C
To cam groove
D
(4) Tu guide cam
(5) Capstan motor
(2) Shifter drive
lever assembly
D
(3) Loading lever
Groove grease
To cam groove
Item Tightening torque Quantity
B S Tight · M1.4 x L2 70mN·m 2
C CWø1.2-ø3.0-t0.25 1
D Special screw · 40mN·m 4
M1.4 x L1.6
(3) Timing belt
(4) Intermediate gear angle
sub assembly
(1) Intermediate pulley
assembly
(2) Center pulley assembly
B
5.
Item Tightening torque Quantity
B S Tight · M1.4 x L2 70mN·m 1
6.
Item Tightening torque Quantity
E Special screw · 40mN·m 2
M1.4 x L1.5
Enter part of
convexity
rear surface
Main chassis assembly
(Rear surface)
(1)Slide chassis guide
B-3
B-5
B-2
A-3
303
361
301
(1) Pinch control lever
Main chassis assembly
(Front surface)
(2) Pinch drive lever
4.
314
325
463
301
441
B-6
B-1
B-4
(1) Mode switch
A-1
Mode FPC
A-2
309
302
379
370
371
304
310
369
314
(1) EJECT
lever
Positioning
hole
(2) Lock lever guide
305
311
314
462
306
386
Drawing part
grease
Mechanism fixing angle
366
312 364 365 421
459
367
Guide rail sub assembly
(Rear surface)
Phase match check
Phase match check
(1) Guide rail sub
assembly
(5) Coupling
gear
(4) Sub cam
Positioning hole
B
E
E
