Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
123
VL-SD20U
VL-PD3AS/AH/AE
16. REPLACEMENT PARTS LIST/
ELECTRICAL PARTS LIST
Parts marked with
"
å
"
are important for maintaining the safety of the
set. Be sure to replace these parts with specified ones for maintaining
the safety and performance of the set.
"
HOW TO ORDER REPLACEMENT PARTS
"
★MARK : SPARE PARTS-DELIVERY SECTION:ALL JAPAN
To have your order filled promptly and correctly, please furnish
the following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
5. PRICE CODE
å MARK: SAFETY RELATED PARTS
PWB ASSEMBLY IS NOT REPLACEMENT ITEM
Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTK2963PM01 MAIN1 PWB Unit —
(VL-PD3AS)
DUNTK2963PM02 MAIN1 PWB Unit —
(VL-PD3AH)
DUNTK2963PM03 MAIN1 PWB Unit —
(VL-PD3AE/AEW)
DUNTK2963PM04 MAIN1 PWB Unit —
(VL-PD3AEX)
DUNTK2964PM01 MAIN2 PWB Unit —
(VL-PD3AS)
DUNTK2964PM02 MAIN2 PWB Unit —
(VL-PD3AH)
DUNTK2964PM03 MAIN2 PWB Unit —
(VL-PD3AE/AEW)
DUNTK2964PM04 MAIN2 PWB Unit —
(VL-PD3AEX)
DUNTK2965QA01 CAMERA HEAD PWB Unit —
DUNTK2966QA01 POWER2 PWB Unit —
DUNTK2875QA04 LCD PWB Unit —
RAMP-0033TAN1 Head Amp PWB Unit —
TUNER AND ASSEMBLY UNITS
RUNTK0343TAZZ Remote Control Receive AM
Unit
RUNTK0371TAZZ JOINT PWB Unit AS
EXPLODED VIEWS
IC408 RH-iX0793TAZZ IX0793TA, ECC External AX
Memory
IC452 RH-iX0710TAN1 IX0710TA, Codec/ECC/ BE
PCM/CLK.Gen
IC601 VHiBH7761KV-1 BH7761KV, Audio I/O AS
IC602 VHiNJM2143R-1 NJM2143R, Amp AE
IC701 RH-iX0835TAZZ IX0835TA AY
IC702 VHiM24C16W6-1 M24C16W6, E
2
PROM AG
IC703 RH-iX0804TAZZ IX0804TA AM
IC704 VHiTC7W04U/-1 TC7W04U, Inverter AD
IC751 VHiS84235F/-1 S84235F, Battery Backup/ AL
Sys 3V Regulator
IC1602 VHiPCM3006T-1 PCM3006T, 16bit ADC/DAC AS
IC3701 RH-iX0819TAZZ IX0819TA, Svart/Lens AX
Control Micon
IC4401 RH-iX0707TAZZ IX0707TA, Digital ADC/DACBC
Decoder/Encoder
IC4461 VHiTC4W53U/-1 TC4W53U, VCTL SW AF
IC4471 VHiTC7S04U/-1 TC7S04U, Inverter AE
IC5002 VHiLV4051AT-1 LV4051AT, Multi Plexer AE
TRANSISTORS
Q601 VSFMG12////-1 FMG12 AD
Q602 VSRN4984///-1 RN4984 AC
Q603 VSHN1B04FU/-1 HN1B04FU AC
Q604 VSHN2A01FU/-1 HN2A01FU AC
Q605 VSRT1N441U/-1 RT1N441U AB
Q606 VSRN4984///-1 RN4984 AC
Q701 VSUN9214///-1 UN9214 AB
Q702 VS2SA1989R/-1 2SA1989R AB
Q4431 VSRN1704///-1 RN1704 AC
Q4432 VSHN2A01FU/-1 HN2A01FU AC
Q4433 VSHN2A01FU/-1 HN2A01FU AC
Q4434 VSHN2A01FU/-1 HN2A01FU AC
Q4461 VSHN2A01FU/-1 HN2A01FU AC
Q4462 VS2SC5383F/-1 2SC5383F AB
Q4471 VSHN1B04FU/-1 HN1B04FU AC
Q4472 VS2SA1989R/-1 2SA1989R AB
Q4481 VSHN1B04FU/-1 HN1B04FU AC
Q4482 VSHN1B04FU/-1 HN1B04FU AC
Q5001 VSHN2C01FU/-1 HN2C01FU AC
Q5002 VSHN2C01FU/-1 HN2C01FU AC
Q5003 VSRT1N441U/-1 RT1N441U AB
Q5004 VS3LN01S///-1 3LN01S AC
Q5005 VSHN2C01FU/-1 HN2C01FU AC
Q5006 VSRT1N441U/-1 RT1N441U AB
Q5007 VS2SA1989R/-1 2SA1989R AB
Q7800 VSHN2A01FU/-1 HN2A01FU AC
Q7801 VSRN1704///-1 RN1704 AC
Q7820 VSHN1B04FU/-1 HN1B04FU AC
Q7830 VSHN1B04FU/-1 HN1B04FU AC
Q7860 VS2SA1989R/-1 2SA1989R AB
Q7861 VS2SA1989R/-1 2SA1989R AB
Q7862 VS2SA1989R/-1 2SA1989R AB
DIODES
D403 VHDHVU362//-1 HVU362 AE
D404 VHDHVU362//-1 HVU362 AE
D471 VHDHVU362//-1 HVU362 AE
D472 VHDHVU359TR-1 HVU359TR AE
D701 VHDDA221///-1 DA221 AB
D4451 VHDKV1812K/-1 KV1812K AD
D4452 VHDKV1812K/-1 KV1812K AD
D5001 VHDMA2S111/-1 MA2S111 AC
D5002 VHDMA132WK/-1 MA132WK AA
PACKAGED CIRCUITS
X401 RCRSC0160TAZZ Crystal, CRSC0160TA AH
X701 RCRSC0032TAZZ Crystal, CRSC0032TA AG
X4451 RCRSC0167TAZZ Crystal, CRSC0167TA AM
COILS
FL403 RFiLC0164TAZZ Filter, FiLC0164TA AH
FL701 RFiLC0072TAZZ Filter, FiLC0072TA AE
FL3701 RFiLC0079TAZZ Filter, FiLC0079TA AE
DUNTK2963PM01(VL-PD3AS)
DUNTK2963PM02(VL-PD3AH)
DUNTK2963PM03(VL-PD3AE/AEW)
DUNTK2963PM04(VL-PD3AEX)
MAIN1 PWB UNIT
INTEGRATED CIRCUITS
IC151 VHiADS933Y/-1 ADS933Y, A/D Converter AR
IC201 RH-iX0706TAZZ IX0706TA, Digital Signal BC
Process
IC202 RH-iX0793TAZZ IX0793TA, 16M-SDRAM AX
IC401 VHiNJU7012F-1 NJU7012F, Amp AE
IC405 VHiNJU7012F-1 NJU7012F, DC Amp AE
IC407 RH-iX0793TAZZ IX0793TA, Codec External AX
Memory
To Next Page
