Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
125
VL-SD20U
VL-PD3AS/AH/AE
C1601 VCSATA0JJ106M 10 6.3V Tantalum AD
C1602 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1603 VCKYTV1AB105K 1 10V Ceramic AD
C1604 VCKYTV1AB105K 1 10V Ceramic AD
C1605 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1607 VCSATA0JJ106M 10 6.3V Tantalum AD
C1608 VCSATA0JJ106M 10 6.3V Tantalum AD
C1609 VCKYCZ1HB222K 2200p 50V Ceramic AB
C1610 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1611 VCKYTV1CB224K 0.22 16V Ceramic AB
C1612 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1613 VCSATA1AJ475M 4.7 10V Tantalum AC
C1614 VCKYCZ1HB222K 2200p 50V Ceramic AB
C1615 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C1616 VCSATA1AJ475M 4.7 10V Tantalum AC
C1617 VCKYTV1CB224K 0.22 16V Ceramic AB
C3701 VCKYCZ1CB103K 0.01 16V Ceramic AB
C3702 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C3703 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C3705 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C3707 VCKYTV1AB105K 1 10V Ceramic AD
C3708 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C3709 VCKYCZ1HB102K 1000p 50V Ceramic AB
C4401 RC-KZ0083TAZZ Capacitor AD
C4402 RC-KZ0083TAZZ Capacitor AD
C4403 RC-KZ0083TAZZ Capacitor AD
C4404 RC-KZ0083TAZZ Capacitor AD
C4405 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4406 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4410 RC-KZ0083TAZZ Capacitor AD
C4411 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4412 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4417 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4419 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4420 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4421 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4422 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4423 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4424 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4430 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4433 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4437 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4443 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4444 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4448 VCSAPR0JJ106M 10 6.3V Tantalum AD
C4449 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4451 VCCCCZ1HH270J 27p 50V Ceramic AB
C4454 VCCCCZ1HH270J 27p 50V Ceramic AB
C4461 VCSATA1AJ106M 10 10V Tantalum AC
C4462 VCKYCZ1EB682K 6800p 25V Ceramic AB
C4463 VCKYCZ1EB682K 6800p 25V Ceramic AB
C4464 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4465 VCKYCZ1AB104K 0.1 10V Ceramic AB
C4466 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4481 VCSAPR0JJ106M 10 6.3V Tantalum AD
C4482 VCKYCZ1CB103K 0.01 16V Ceramic AB
C4485 VCKYCZ1AF104Z 0.1 10V Ceramic AB
C5020 VCKYCY1CF104Z 0.1 16V Ceramic AA
C7820 VCCCCZ1HH150J 15p 50V Ceramic AB
C7821 VCCCCZ1HH680J 68p 50V Ceramic AB
C7830 VCCCCZ1HH150J 15p 50V Ceramic AB
C7831 VCCCCZ1HH680J 68p 50V Ceramic AB
C7832 VCSAPR0JJ106M 10 6.3V Tantalum AD
C7833 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7840 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7841 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7842 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7843 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7854 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7856 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7858 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7860 VCKYCZ1CB103K 0.01 16V Ceramic AB
C7861 VCSAPR0JJ106M 10 6.3V Tantalum AD
RESISTORS
R152 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R153 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R154 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R155 VRS-CZ1JF221J 220 1/16W Metal Oxide AA
R156 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R157 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R158 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R159 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R160 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R161 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R162 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R163 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R164 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R165 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R166 VRS-CZ1JF220J 22 1/16W Metal Oxide AA
R202 VRK-SB1FF473J 47k 0.0315W AB
Metal Composition
R203 VRK-SB1FF473J 47k 0.0315W AB
Metal Composition
R204 VRK-SB1FF473J 47k 0.0315W AB
Metal Composition
R214 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R215 VRS-CZ1JF473J 47k 1/16W Metal Oxide AA
R226 VRK-SB1FF562J 5.6k 0.0315W AC
Metal Composition
R227 VRK-SB1FF562J 5.6k 0.0315W AC
Metal Composition
R240 VRS-CZ1JF473J 47k 1/16W Metal Oxide AA
R241 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R242 VRS-CZ1JF102J 1k 1/16WMetal Oxide AA
R243 VRS-CZ1JF473J 47k 1/16W Metal Oxide AA
R244 VRS-CZ1JF473J 47k 1/16W Metal Oxide AA
R245 VRS-CZ1JF102J 1k 1/16WMetal Oxide AA
R246 VRS-CZ1JF102J 1k 1/16WMetal Oxide AA
R247 VRS-CZ1JF102J 1k 1/16WMetal Oxide AA
R401 VRS-CZ1JF102J 1k 1/16WMetal Oxide AA
R402 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R403 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R404 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R405 VRS-CY1JF000J 0 1/16W Metal Oxide AA
R406 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R407 VRS-CZ1JF153J 15k 1/16W Metal Oxide AA
R410 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R411 VRS-CZ1JF154J 150k 1/16W Metal Oxide AA
R412 VRS-CZ1JF334J 330k 1/16W Metal Oxide AA
R413 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R416 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R417 VRS-CZ1JF105J 1M 1/16WMetal Oxide AA
R418 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R428 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R431 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R432 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R435 VRS-CZ1JF105J 1M 1/16WMetal Oxide AA
R436 VRS-CZ1JF224J 220k 1/16W Metal Oxide AA
R437 VRS-CZ1JF224J 220k 1/16W Metal Oxide AA
R438 VRS-CZ1JF101J 100 1/16W Metal Oxide AA
R440 VRS-CZ1JF393J 39k 1/16W Metal Oxide AA
R441 VRS-CZ1JF563J 56k 1/16W Metal Oxide AA
R442 VRS-CZ1JF114J 110k 1/16W Metal Oxide AB
R443 VRS-CZ1JF105J 1M 1/16WMetal Oxide AA
R446 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R453 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R454 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R462 VRS-CZ1JF103J 10k 1/16W Metal Oxide AA
R467 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R468 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R469 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R470 VRS-CZ1JF000J 0 1/16W Metal Oxide AA
R471 VRS-CZ1JF472J 4.7k 1/16W Metal Oxide AA
R476 VRS-CZ1JF105J 1M 1/16WMetal Oxide AA
R477 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R478 VRS-CZ1JF823J 82k 1/16W Metal Oxide AA
R603 VRS-CZ1JF102J 1k 1/16WMetal Oxide AA
R609 VRS-CZ1JF102J 1k 1/16WMetal Oxide AA
