Sharp XG-E690UB

Remote control signal receiver window
Focusing ring
Cooling fan (exhaust vent)
Carrying handle
E-4
Location of Controls
FRONT VIEW
OUTIN
L
AUDIOVIDEOAUDIOVIDEO
S-VIDEO
RRL COMPUTER
INPUT OUTPUT
COMPUTER
RGB
OFF ON
FILTER
FILTER ON/OFF switch
COMPUTER RGB INPUT
connector (HD-15)
COMPUTER RGB OUTPUT
connector (HD-15)
MAIN POWER button
KEYSTONE/SIZE
CORRECTION knob
S-VIDEO INPUT
(4-pin mini DIN)
VIDEO INPUT
Video: RCA
Audio: RCA
VIDEO OUTPUT
Video: RCA
Audio: RCA
COMPUTER
AUDIO INPUT
(Stereo mini jack)
Cooling fan (intake vent) Air filter
Speaker
REAR VIEW
POWER ON/OFF button E-ZOOM/PANNING button
ADJUSTMENT (
ƒ
/
∂
) buttons
ADJUSTMENT (
ß
/
©
) buttonsVOLUME UP-DOWN buttons
MUTE button
POWER indicator
LAMP REPLACEMENT indicator
TEMPERATURE WARNING
indicator
MENU button
BLACK SCREEN button
INPUT SELECT button
OPERATION PANEL ON SIDE OF PROJECTOR
