Sharp XG-P560W - Adjusting the Position Horizontally and Vertically; Returning to the Default Video Wall Setup; Assigning the Projected Image on the Video Wall Setup

-47
Video Wall Projection
The numbers of the projector refer to the numbers
of the projected positions.
12
2
33
45
5
56
789
1
2
3
4
5
6
7
8
9
2
The numbers of the projector refer to the numbers
of the projected positions.
123
456
789
1
2
3
4
5
6
7
8
9
Assigning the Projected Image on the Video Wall Setup
Followings are examples for assigning the projected images for the front and rear projections.
Front Projection Rear Projection
Adjusting the Position
Horizontally and Vertically
Click “UP”, “DOWN”, “LEFT” or “RIGHT” to the po-
sition of the projected image.
Returning to the Default
Video Wall Setup
1 Select “1 X 1” on “Division”.
2 Click the assigning button 1.
• The video wall setup will return to the de-
fault settings.
