Fixed Wide Lens (AN-P12EX)
F2.5, f=17.1 mm
16:10 Signal Input (Normal Mode)
The formula for picture size and projection distance
[m/cm]
L (m) = 0.02619
χ
H1 (cm) =
–
0.96916
χ
H2 (cm) =
–
0.37689
χ
W (cm) = ±0.23691
χ
[Feet/inches]
L (ft) = 0.02619
χ
/ 0.3048
H1 (in) =
–
0.96916
χ
/ 2.54
H2 (in) =
–
0.37689
χ
/ 2.54
W (in) = ±0.23691
χ
/ 2.54
χ
: Picture size (diag.) (in/cm)
L: Projection distance (m/ft)
H1: Lower distance from the lens center to the bottom of the image (cm/in)
H2: Upper distance from the lens center to the bottom of the image (cm/in)
W: Distance from the lens center to the center of the image (cm/in)
Note
• Allow a margin of error in the value in the diagrams above.
• When the distance from the lens center to the bottom of the image [H] is a negative number, this indicates
that the bottom of the image is below the lens center.
The formula for picture size and projection distance
[m/cm]
L (m) = 0.02965
χ
H1 (cm) =
–
1.09716
χ
H2 (cm) =
–
0.42667
χ
W (cm) = ±0.26823
χ
[Feet/inches]
L (ft) = 0.02965
χ
/ 0.3048
H1 (in) =
–
1.09716
χ
/ 2.54
H2 (in) =
–
0.42667
χ
/ 2.54
W (in) = ±0.26823
χ
/ 2.54
χ
: Picture size (diag.) (in/cm)
L: Projection distance (m/ft)
H1: Lower distance from the lens center to the bottom of the image (cm/in)
H2: Upper distance from the lens center to the bottom of the image (cm/in)
W: Distance from the lens center to the center of the image (cm/in)
4:3 Signal Input (Normal Mode)
Screen Size and Projection Distance
Picture (Screen) size Projection distance
Distance from the lens center to
the bottom of the image [H]
Distance from the lens
center to the center of
the image [W]
Diag. [
χ
]
Width Height [L] Lower [H1] Upper [H2]
230''
200''
150''
120''
100''
80''
60''
(584 cm)
(508 cm)
(381 cm)
(305 cm)
(254 cm)
(203 cm)
(152 cm)
495 cm
431 cm
323 cm
258 cm
215 cm
172 cm
129 cm
(195'')
(170'')
(127'')
(102'')
(85'')
(68'')
(51'')
310 cm
269 cm
202 cm
162 cm
135 cm
108 cm
81 cm
(122'')
(106'')
(79'')
(64'')
(53'')
(42'')
(32'')
–222.9 cm
–193.8 cm
–145.4 cm
–116.3 cm
–96.9 cm
–77.5 cm
–58.1 cm
(–87
49
/
64
")
(–76
5
/
16
")
(–57
15
/
64
")
(–45
25
/
32
")
(–38
5
/
32
")
(–30
17
/
32
")
(–22
57
/
64
")
–86.7 cm
–75.4 cm
–56.5 cm
–45.2 cm
–37.7 cm
–30.2 cm
–22.6 cm
(–34
1
/
8
")
(–29
43
/
64
")
(–22
1
/
4
")
(–17
13
/
16
")
(–14
27
/
32
")
(–11
7
/
8
")
(–8
29
/
32
")
±54.5cm
±47.4cm
±35.5cm
±28.4cm
±23.7cm
±19.0cm
±14.2cm
(21
29
/
64
")
(18
21
/
32
")
(13
63
/
64
")
(11
3
/
16
")
(9
21
/
64
")
(7
15
/
32
")
(5
19
/
32
")
6.0 m
5.2 m
3.9 m
3.1 m
2.6 m
2.1 m
1.6 m
(19' 9")
(17' 2")
(12' 11")
(10' 4")
(8' 7")
(6' 10")
(5' 2")
Picture (Screen) size Projection distance
Distance from the lens center to
the bottom of the image [H]
Distance from the lens
center to the center of
the image [W]
Diag. [
χ
]
Width Height [L] Lower [H1] Upper [H2]
200''
150''
120''
100''
80''
70''
60''
(508 cm)
(381 cm)
(305 cm)
(254 cm)
(203 cm)
(178 cm)
(152 cm)
406 cm
305 cm
244 cm
203 cm
163 cm
142 cm
122 cm
(160'')
(120'')
(96'')
(80'')
(64'')
(56'')
(48'')
305 cm
229 cm
183 cm
152 cm
122 cm
107 cm
91 cm
(120'')
(90'')
(72'')
(60'')
(48'')
(42'')
(36'')
–219.4 cm
–164.6 cm
–131.7 cm
–109.7 cm
–87.8 cm
–76.8 cm
–65.8 cm
(–86
25
/
64
")
(–64
51
/
64
")
(–51
53
/
64
")
(–43
3
/
16
")
(–34
9
/
16
")
(–30
15
/
64
")
(–25
59
/
64
")
–85.3 cm
–64.0 cm
–51.2 cm
–42.7 cm
–34.1 cm
–29.9 cm
–25.6 cm
(–33
19
/
32
")
(–25
13
/
64
")
(–20
5
/
32
")
(–16
51
/
64
")
(–13
7
/
16
")
(–11
49
/
64
")
(–10
5
/
64
")
±53.6cm
±40.2cm
±32.2cm
±26.8cm
±21.5cm
±18.8cm
±16.1cm
(21
1
/
8
")
(15
27
/
32
")
(12
43
/
64
")
(10
9
/
16
")
(8
29
/
64
")
(7
25
/
64
")
(6
11
/
32
")
5.9 m
4.4 m
3.6 m
3.0 m
2.4 m
2.1 m
1.8 m
(19' 5")
(14' 7")
(11' 8")
(9' 9")
(7' 9")
(6' 10")
(5' 10")
