Sharp XG-P610X Setup Manual

-49
Video Wall Projection
Projector 1 :
Master
Projector 2 :
Slave
Projector 3:
Slave
Projector 4 :
Slave
RGB cable
5BNC to mini
D-sub 15 pin cable
RGB
cable
RGB
cable
RGB
cable
LAN terminal
VIDEO terminal
COMPUTER/COMPONENT2 terminal
MONITOR OUT (FOR COMPUTER/
COMPONENT1, 2) terminal
LAN terminal
LAN terminal
LAN terminal
VIDEO terminal
VIDEO terminal
VIDEO terminal
MONITOR OUT (FOR COMPUTER/
COMPONENT1, 2) terminal
MONITOR OUT (FOR COMPUTER/
COMPONENT1, 2) terminal
COMPUTER/COMPONENT1 terminal
COMPUTER/COMPONENT1 terminal
COMPUTER/COMPONENT1 terminal
COMPUTER/COMPONENT1 terminal
Composite video cable
Distributor
Video equipment
LAN cable
(straight-through type)
Computer
Computer
Hub
Setting up the Video Wall Projection
Application
Using “Stack Setting” and “Set Inputs” functions together allows you to control the video wall with one
remote control.
This part shows an example of a connecting procedure for inputting the video signals to the video wall
based on the example in the previous section.
