Setting Up the Projector (Continued)
[For XG-SV100W]
16:10 Signal Input (Normal Mode)
Picture (Screen) size Projection distance [L]
Distance from the lens center to
the bottom of the image [H]
Distance from the
lens center
to the center of
the image[W]
Diagonal [
F
] Width Height Minimum [L1] Maximum [L2] Lower [H1] Upper [H2]
500" (1270 cm) 1077 cm (424") 673 cm (265") 16.2 m (53' 3") 32.5 m (106' 8") -673 cm (-265") 0 cm (0") ±255 cm (±100
7
/
16
")
400" (1016 cm) 862 cm (339") 538 cm (212") 13.0 m (42' 7") 26.0 m (85' 4") -538 cm (-212") 0 cm (0") ±204 cm (±80
23
/
64
")
300" (762 cm) 646 cm (254") 404 cm (159") 9.7 m (32' 0") 19.5 m (64' 0") -404 cm (-159") 0 cm (0") ±153 cm (±60
17
/
64
")
250" (635 cm) 538 cm (212") 337 cm (132") 8.1 m (26' 8") 16.3 m (53' 4") -337 cm (-132
1
/
2
") 0 cm (0") ±128 cm (±50
7
/
32
")
200" (508 cm) 431 cm (170") 269 cm (106") 6.5 m (21' 4") 13.0 m (42' 8") -269 cm (-106") 0 cm (0") ±102 cm (±40
11
/
64
")
150" (381 cm) 323 cm (127") 202 cm (79") 4.9 m (16' 0") 9.8 m (32' 0") -202 cm (-79
1
/
2
") 0 cm (0") ±77 cm (±30
9
/
64
")
120" (305 cm) 258 cm (102") 162 cm (64") 3.9 m (12' 9") 7.8 m (25' 7") -162 cm (-63
19
/
32
") 0 cm (0") ±61 cm (±24
7
/
64
")
100" (254 cm) 215 cm (85") 135 cm (53") 3.2 m (10' 8") 6.5 m (21' 4") -135 cm (-53") 0 cm (0") ±51 cm (±20
3
/
32
")
80" (203 cm) 172 cm (68") 108 cm (42") 2.6 m (8' 6") 5.2 m (17' 1") -108 cm (-42
13
/
32
") 0 cm (0") ±41 cm (±16
5
/
64
")
60" (152 cm) 129 cm (51") 81 cm (32") 1.9 m (6' 5") 3.9 m (12' 10") -81 cm (-31
51
/
64
") 0 cm (0") ±31 cm (±12
3
/
64
")
40" (102 cm) 86 cm (34") 54 cm (21") 1.3 m (4' 3") 2.6 m (8' 6") -54 cm (-21
13
/
64
") 0 cm (0") ±20 cm (±8
1
/
32
")
4:3 Signal Input (Normal Mode)
Picture (Screen) size Projection distance [L]
Distance from the lens center to
the bottom of the image [H]
Distance from the
lens center
to the center of
the image[W
]
Diagonal [
F
] Width Height Minimum [L1] Maximum [L2] Lower [H1] Upper [H2]
500" (1270 cm) 1016 cm (400") 762 cm (300") 18.4 m (60' 4") 36.8 m (120' 9") -762 cm (-300") 0 cm (0") ±289 cm (±113
5
/
7
")
400" (1016 cm) 813 cm (320") 610 cm (240") 14.7 m (48' 3") 29.5 m (96' 8") -610 cm (-240") 0 cm (0") ±231 cm (±90
31
/
32
")
300" (762 cm) 610 cm (240") 457 cm (180") 11.0 m (36' 2") 22.1 m (72' 6") -457 cm (-180") 0 cm (0") ±173 cm (±68
7
/
32
")
250" (635 cm) 508 cm (200")
381 cm (150") 9.2 m (30' 2") 18.4 m (60' 5") -381 cm (-150") 0 cm (0") ±144 cm (±56
55
/
64
")
200" (508 cm) 406 cm (160")
305 cm (120") 7.4 m (24' 1") 14.7 m (48' 4") -305 cm (-120") 0 cm (0") ±116 cm (±45
31
/
64
")
150" (381 cm) 305 cm (120")
229 cm (90") 5.5 m (18' 1") 11.0 m (36' 3") -229 cm (-90") 0 cm (0") ±87 cm (±34
7
/
64
")
120" (305 cm) 244 cm (96") 183 cm (72") 4.4 m (14' 6") 8.8 m (29' 0") -183 cm (-72") 0 cm (0") ±69 cm (±27
19
/
64
")
100" (254 cm) 203 cm (80")
152 cm (60") 3.7 m (12' 1") 7.4 m (24' 2") -152 cm (-60") 0 cm (0") ±58 cm (±22
47
/
64
")
80" (203 cm) 163 cm (64") 122 cm (48") 2.9 m (9' 8") 5.9 m (19' 4") -122 cm (-48") 0 cm (0") ±46 cm (±18
3
/
16
")
70" (178 cm) 142 cm (56")
107 cm (42") 2.6 m (8' 5") 5.2 m (16' 11") -107 cm (-42") 0 cm (0") ±40 cm (±15
59
/
64
")
60" (152 cm) 122 cm (48")
91 cm (36") 2.2 m (7' 3") 4.4 m (14' 6") -91 cm (-36") 0 cm (0") ±35 cm (±13
41
/
64
")
40" (102 cm) 81 cm (32")
61 cm (24") 1.5 m (4' 10") 2.9 m (9' 8") -61 cm (-24") 0 cm (0") ±23 cm (±9
3
/
32
")
When using the projector with screen sizes not listed in the above charts, calculate the values according to the formulas.
16:10 Signal 4:3 Signal
[m/cm] [Feet/inches] [m/cm] [Feet/inches]
L1: Minimum projection distance (m/ft) 0.03247
F
0.03247
F
/ 0.3048
0.03676
F
0.03676
F
/ 0.3048
L2: Maximum projection distance (m/ft)
0.06504
F
0.06504
F
/ 0.3048 0.07363
F
0.07363
F
/ 0.3048
H1: Lower distance from the lens center to the
bottom of the image (cm/in)
-1.3462
F
-1.3462
F
/ 2.54
-1.524
F
-1.524
F
/ 2.54
H2: Upper distance from the lens center to the
bottom of the image (cm/in)
0
F
0
F
/ 2.54 0
F
0
F
/ 2.54
W: Distance from the lens center to the center of the
image (cm/in)
±0.51026
F
±0.51026
F
/ 2.54
±0.57765
F
±0.57765
F
/ 2.54
F
: Picture diagonal size : 40"-500"
Allow a margin of error in the value in the diagrams above.
When the distance from the lens center to the bottom of the image [H] is a negative number, this indicates
that the bottom of the image is below the lens center.
•
•
Note
