Sharp XL-1000H

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
XL-1000H/1100H
INTEGRATED CIRCUITS
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC401 VHILC75342M-1 J AN Function/Volume Equalizer,
LC75342M
IC681 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC701 RH-IX0037SJZZ J AW System Microcomputer/FL Driver,
IX0037SJ
IC801 VHITA2109F/-1 J AL Servo Pre Amp.,TA2109F
IC802 VHITC9462F/-1 J AZ Servo/Signal Control,TC9462F
IC804 VHIMM1469XH-1 J AN Focus/Tracking/Spin/Sled Driver,
MM1469XH
IC805 VHITA7291S/-1 J AH CD Lid Motor Driver,TA7291S
IC901 VHILA4282//-1 J AM Power Amp.,LA4282
TRANSISTORS
Q101 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q102 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q301 VS2SC380-O/-1 J AC Silicon,NPN,2SC380 O
Q351 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q601,602 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q603 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q604,605 VS2SD2012Y/-1 J AF Silicon,NPN,2SD2012 Y
Q606 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q607 VS2SD2012Y/-1 J AF Silicon,NPN,2SD2012 Y
Q608 VSKRA102M//-1 J AC Digital,PNP,KRA102 M
Q609 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q681 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q683 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q702,703 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q706 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q707,708 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q709 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q801 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q802 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q861 VS2SB562-C/-1 J AD Silicon,PNP,2SB562 C
Q901 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q902 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q903 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
[XL-1100H Only]
Q904 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
[XL-1100H Only]
Q907 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q908 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
DIODES
D301~304 VHD1N4148//-1 J AA Silicon,1N4148
D308 VHD1N4148//-1 J AA Silicon,1N4148
D401~403 VHD1N4004//-1 J AB Silicon,1N4004
D602 VHD1N4148//-1 J AA Silicon,1N4148
D604 VHD1N4148//-1 J AA Silicon,1N4148
1 D651~654 VHD1N5402M/-1 J AE Silicon,1N5402M
1 D657~660 VHD1N4004//-1 J AB Silicon,1N4004
D681~685 VHD1N4004//-1 J AB Silicon,1N4004
D688,689 VHD1N4004//-1 J AB Silicon,1N4004
D720~723 VHD1N4148//-1 J AA Silicon,1N4148
D801 VHPDB5306X+-1 J AR LED,DB5306X [XL-1100H]
D901,902 VHD1N4004//-1 J AB Silicon,1N4004 [XL-1100H Only]
LED701,702 VHPSLI343YC-1 J LED,SLI343YC [XL-1000H Only]
LED801 VHPAUY3333+-1 J AF LED,AUY3333 [XL-1000H]
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD601 VHEDZ130BSA-1 J AC Zener,13V,DZ13BSA
ZD602 VHEDZ8R2BSC-1 J AB Zener,8.2V,DZ8.2BSC
ZD683,684 VHEMTZJ160C-1 J AB Zener,16V,MTZJ16C
ZD701 VHEDZ3R3BSB-1 J AB Zener,3.3V,DZ3.3BSB
ZD901 VHEDZ240BSD-1 J AB Zener,24V,DZ24BSD
[XL-1100H Only]
ZD902 VHEDZ5R6BSB-1 J AC Zener,5.6V,DZ5.6BSB
[XL-1100H Only]
FILTERS
CF301,302 RFILF0072AFZZ J AG FM IF
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0003SJZZ J AF AM IF
TRANSFORMERS
T302 RCILA0007SJZZ J AG AM Tracking
T306 RCILB0009SJZZ J AG AM Band Coverage
T351 RCILI0004SJZZ J AF AM IF
1 T651 RTRNP0058SJZZ J AT Power Transformer (Main)
1 T681 RTRNP0057SJZZ J AL Power Transformer (Sub)
COILS
L341 RBLN-0001AWZZ J AD Balun
L342 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L354 RFILL0001AWZZ J AE Low Pass Filter
L601,602 RCILZ0024AWZZ J AC 3 µH,Choke
L603~605 VP-DH100K0000 J AB 10 µH,Choke
L702 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L801 VP-DH100K0000 J AB 10 µH,Choke
L802 VP-XHR82K0000 J AC 0.82 µH
L803 VP-DH100K0000 J AB 10 µH,Choke
L806 VP-DH100K0000 J AB 10 µH,Choke
1 LF651 RCILZ0003SJZZ J AE Line Filter
VARIABLE RESISTOR
VR351 RVR-M0999AFZZ J AB 10 kohm (B),Semi-VR
[FM Mute Level]
VARIABLE CAPACITOR
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VIBRATORS
X351 RCRM-0007SJZZ J AG VCO,456 kHz
X352 RCRSP0006SJZZ J AF Crystal,4.5 MHz
X701 RCRM-0008SJZZ J AG Ceramic,8 MHz
X702 RCRSP0011AWZZ J AC Crystal,32.768 kHz
X801 RCRSP0002SJZZ J AL Crystal,16.93 MHz
CAPACITORS
C101 VCKYPA1HF223Z J AB 0.022 µF,50V
C102 RC-GZA476AF1E J AB 47 µF,25V,Electrolytic
C103 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C104 VCQYKA1HM823J J AC 0.082 µF,50V,Mylar
C107 VCQYKA1HM823J J AC 0.082 µF,50V,Mylar
C108 RC-GZA107AF1E J AB 100 µF,25V,Electrolytic
C109 RC-GZV477AF1E J AC 470 µF,25V,Electrolytic
C110 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C111 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C112 RC-GZA106AF1H J AB 10 µF,50V,Electrolytic
C113 VCKYPA1HF223Z J AB 0.022 µF,50V
C114 RC-GZV477AF1E J AC 470 µF,25V,Electrolytic
C115 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C116 VCFYFA1HA104J J AC 0.1 µF,50V,Thin Film
C117 VCKYPA1HB471K J AA 470 pF,50V
C118 VCKYPA1HB471K J AA 470 pF,50V
C119 VCCSPA1HL680J J AA 68 pF,50V
C120 VCKYPA1HB681K J AA 680 pF,50V
C125 RC-GZW228AF1H J AH 2200 µF,50V,Electrolytic
C301 VCKYPA1HF123Z J AD 0.012 µF,50V
C302 VCKYCY1HB102K J AA 0.001 µF,50V
C329 VCKYCY1EF223Z J AB 0.022 µF,25V
C330 VCCCPA1HH120J J AA 12 pF (CH),50V
C331 VCKYCY1EF473Z J AB 0.047 µF,25V
C332 VCKYPA1HF223Z J AB 0.022 µF,50V
C334 VCCUPA1HJ270J J AA 27 pF (UJ),50V
C335 VCKYCY1HB561K J AA 560 pF,50V
C337 VCKYPA1HF223Z J AB 0.022 µF,50V
C341 VCKYCY1EF223Z J AB 0.022 µF,25V
C343 VCCSCY1HL330J J AD 33 pF,50V
C345~347 VCKYCY1EF223Z J AB 0.022 µF,25V
C348 RC-GZA107AF1C J AB 100 µF,16V,Electrolytic
C349 VCKYCY1HB102K J AA 0.001 µF,50V
C350,351 VCKYCY1EF223Z J AB 0.022 µF,25V
C352 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C353,354 VCKYCY1EF223Z J AB 0.022 µF,25V
C355 VCCSCY1HL220J J AD 22 pF,50V
C356 VCKYCY1HB102K J AA 0.001 µF,50V
C357 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
– 1 –
